10G XGSPON ONU SFF Optical Transceiver Module
10G XGSPON ONU SFF Optical Transceiver Module is a CZT fiber optic and SFP interconnect product for data center, telecom, and optical networking programs. It is supported by local product imagery. Confirm final data rate, port count, reach, cage construction, plating, thermal path, and compliance requirements before sample release.
Key Features
- SFF package delivers 10G XGS-PON symmetric connectivity in compact form factor
- Supports ITU-T G.9807.1 XGS-PON with 9.9532Gbps upstream and downstream
- 1270nm burst-mode TX and 1577nm continuous-mode RX wavelengths
- Designed for embedded integration into fixed-port ONU and gateway hardware
- High receiver sensitivity supporting standard 29dB ODN class N1/N2 loss budgets
Key Specifications
- Data Rate: 10Gbps
- Center Wavelength: 1270nm / 1577nm
- Transmission Distance: 20km
- Supply Voltage: -0.3~3.7V
- +2 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
10G XGSPON ONU SFF Optical Transceiver Module Specifications
Data Rate10Gbps
Center Wavelength1270nm / 1577nm
Transmission Distance20km
Supply Voltage-0.3~3.7V
Relative Humidity5~95%
Power Consumption<2W
Typical Applications
Fixed-port FTTH ONU and residential gateway hardware integration
Embedded 10G PON module for compact ONU appliance designs
Telecom equipment OEM manufacturing requiring soldered PON optics
Enterprise CPE devices with integrated XGS-PON fiber access
Multi-service ONU platforms combining PON and LAN interfaces
Frequently Asked Questions
What is the difference between the SFF and SFP+ form factor for XGS-PON ONU?
The SFF (Small Form Factor) module is designed for permanent soldered or fixed-connector integration into ONU PCBs, while the SFP+ version is pluggable and hot-swappable. SFF is preferred for cost-optimized, fixed-configuration ONU hardware where field replaceability is not required.
Is the 10G XGSPON ONU SFF backward compatible with GPON or XG-PON1 OLTs?
No. The XGS-PON SFF transceiver is designed exclusively for XGS-PON OLTs operating per ITU-T G.9807.1. Compatibility with GPON or XG-PON1 requires different transceiver types with different wavelengths and protocols.
What ODN loss budget classes does this module support?
The module supports N1 and N2 ODN loss budget classes as defined in ITU-T G.9807.1, covering up to 29dB and 31dB of optical path loss respectively. This enables deployment in standard FTTH passive optical distribution networks with typical reach up to 20km.
10G XGSPON ONU SFF Optical Transceiver Module Details
CategorySFP/Optical
SubcategoryOptical Module Series
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
