USB Type-C Connector Selection

Compare USB Type-C connector drawings for contact layout, PCB footprint, and electrical ratings.

Selection & Drawing Review

Use the model drawing to verify contact layout, electrical ratings, and footprint. Connector shape or contact count alone does not establish a data rate or charging power.

34
Product models
34
With specifications
25
With drawing references
9
Drawing on request

Buyer Intent

USB Type-C plugs, receptacles, and interface assemblies

USB-C interfaces for electronics, vehicle interiors, chargers and embedded devices

34
Models with catalog specifications

Interface generation

Confirm USB 2.0, USB 3.x, or charge-only needs before choosing the receptacle.

Mounting style

Compare SMT, DIP, hybrid, mid-mount, vertical, and right-angle layouts.

Shell and retention

Review shell material, grounding, mating durability, and board retention for the final application.

Technical Focus

Core family
USB Type-C receptacles, sockets, and vehicle interface connectors
Mounting
SMT, DIP, hybrid, mid-mount, right-angle, vertical
Key checks
Pin count, shell design, insertion force, durability, current rating
Information to provide
Drawing, footprint, plating, shell, and target standard

Applications

Consumer electronics

USB-C board connectors for compact devices and accessories.

Automotive interiors

USB Type-C interface assemblies for in-vehicle connectivity.

Industrial devices

Robust USB-C I/O options for control panels and embedded systems.

Products (34)

BBAC USB Type-C In-Vehicle Connector
Auto

BBAC USB Type-C In-Vehicle Connector

CZT-AV-008

  • Product family: BBAC in-vehicle USB Type-C connector
  • Contact / pin count: confirm from drawing
  • Mating connector: confirm against the drawing
Request Drawing
USB Type-C 16-Contact Vertical SMT Plug
USB

USB Type-C 16-Contact Vertical SMT Plug

10311024F022

  • Interface: USB Type-C
  • Contact Count: 16 populated positions
  • Gender: Male Plug
View Details
USB 2.0 Type-C 16-Contact SMT Receptacle
USB

USB 2.0 Type-C 16-Contact SMT Receptacle

10317016B001

  • Interface: USB 2.0 Type-C
  • Contact Count: 16
  • Gender: Female Receptacle
View Details
USB 2.0 Type-C 16-Contact SMT Receptacle
USB

USB 2.0 Type-C 16-Contact SMT Receptacle

10317016C001

  • Interface: USB 2.0 Type-C
  • Contact Count: 16
  • Gender: Female Receptacle
View Details
USB Type-C Female Receptacle
USB

USB Type-C Female Receptacle

10317106L001

  • Rated Current: 5 A
  • Rated Voltage: 30 V AC
  • Insulation Resistance: 100 MΩ Min
View Details
USB Type-C Female Receptacle
USB

USB Type-C Female Receptacle

10317116D001

  • Rated Current: 5 A
  • Rated Voltage: 30 V AC
  • Insulation Resistance: 100 MΩ Min
View Details
USB Type-C Female Receptacle
USB

USB Type-C Female Receptacle

10317124D003

  • Rated Current: 5 A
  • Rated Voltage: 30 V AC
  • Insulation Resistance: 100 MΩ Min
View Details
USB Type-C Female Receptacle
USB

USB Type-C Female Receptacle

10317124F004

  • Rated Current: 5 A
  • Rated Voltage: 30 V AC
  • Insulation Resistance: 100 MΩ Min
View Details
USB Type-C Female Receptacle
USB

USB Type-C Female Receptacle

10317124F007

  • Rated Current: 5 A
  • Rated Voltage: 30 V AC
  • Insulation Resistance: 100 MΩ Min
View Details
USB Type-C Female Receptacle
USB

USB Type-C Female Receptacle

10317124F011

  • Rated Current: 6 A
  • Rated Voltage: 30 V AC
  • Insulation Resistance: 100 MΩ Min
View Details
USB Type-C Female Receptacle
USB

USB Type-C Female Receptacle

10317124F012

  • Rated Current: 6 A
  • Rated Voltage: 30 V AC
  • Insulation Resistance: 100 MΩ Min
View Details
USB Type-C Female Receptacle
USB

USB Type-C Female Receptacle

10317216F001

  • Rated Current: 5 A
  • Rated Voltage: 30 V AC
  • Insulation Resistance: 100 MΩ Min
View Details
