Expanded I/O Catalog
USB, HDMI, SATA, and power I/O products ready for selection
The I/O catalog now highlights products with downloadable drawings and keeps additional connector families visible for RFQ discussion. Buyers can narrow interface type, mount style, mechanical fit, and specification needs before sampling.
151
I/O products
96
With downloads
55
RFQ families
96
With drawings
I/O Product Lines
USB Type-A
Standard USB Type-A receptacles and plugs in USB 2.0 and USB 3.0/3.2 variants. Vertical, right-angle, and mid-mount options.
USB Type-C
USB Type-C receptacles supporting USB 3.2 Gen 2, USB4, and Thunderbolt. 24-pin, 16-pin, and 6-pin configurations available.
HDMI Type-A / Mini / Micro
HDMI 2.1 compatible connectors in standard Type-A, Mini (Type-C), and Micro (Type-D) form factors for 8K video applications.
DisplayPort
DisplayPort 2.0 and Mini DisplayPort connectors for high-resolution display interfaces in workstations and professional monitors.
SATA Connectors
SATA data and power connectors for SSD and HDD storage interfaces. 7-pin data, 15-pin power, and combo 22-pin configurations.
Type-C Catalog Extract
USB Type-C connector families for mechanical selection
The extracted Type-C catalog is strongest for mapping mechanical connector styles before drawing review: plug assemblies, short-body receptacles, vertical connectors, waterproof mid-mount options, offset PCB designs, and SMT/DIP retention styles.
2006
Dongguan Zhengde founded
600
USB connector staff referenced in catalog
500M
Annual USB production capacity referenced in catalog
4
Core processes: stamping, injection, plating, automation
USB Type-C Plug Assemblies
Male semi-finished parts and plug-with-PCB options for cable, charger, dock, and adapter programs.
Short-Body 16-Pin Receptacles
Compact 16-pin female connector options for space-constrained consumer and embedded electronics.
Vertical Receptacles
Vertical Type-C receptacle variants including H=7.4 and H=9.15 catalog families.
Waterproof Mid-Mount Designs
Sunk-board and externally waterproof Type-C receptacles for equipment that needs sealed I/O access.
Offset PCB / Dual SMT
Offset PCB and dual-SMT connector styles for mechanical alignment and board stacking constraints.
Standard Dual-Row SMT / DIP
Standard receptacle families with dual-row SMT shells and four-leg DIP mechanical anchoring.
Type-C drawing evidence from local catalog
The local Type-C catalog contains mechanical drawing families for vertical, waterproof, offset, dual-SMT, and plug-assembly connector decisions.
Model-Level Table
Representative USB Type-C catalog families
| Family | Catalog Examples | Engineering Review |
|---|---|---|
| Vertical Type-C Receptacle | H=7.4 and H=9.15 catalog variants | Use when the PCB needs a vertical mating direction; confirm height, shell grounding, and board support. |
| Waterproof Mid-Mount | Sunk-board and externally waterproof Type-C receptacle variants | Use for sealed equipment I/O; confirm panel seal, board sink depth, and waterproofing target. |
| Offset PCB / Dual SMT | Offset PCB, dual-SMT, and L6.30 / L=8.85 style catalog references | Use when enclosure alignment or board stacking changes the connector centerline. |
| Short-Body 16-Pin | Compact 16-pin female Type-C receptacle families | Use for lower-speed or charging-focused designs where a full 24-pin USB-C interface is not required. |
| Plug Assembly | Male semi-finished parts, plug with PCB, cable-end components | Use for cable, dock, adapter, and charger programs; confirm shell, PCB, overmold, and cable construction. |
Products (96)
USBUSB 2.0 Type-A Female Receptacle Board/Panel-Mount Connector
10302204B161
- Rated Current: 2 A & 5 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB 2.0 Type-A Female Receptacle Board/Panel-Mount Connector
10302204B167
- Rated Current: 2 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB 2.0 Type-A Female Receptacle Board/Panel-Mount Connector
10302204F201
- Rated Current: 7 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB 2.0 Type-A Female Receptacle Board/Panel-Mount Connector
10302205D023
- Rated Current: 10 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB 2.0 Type-A Female Receptacle Board/Panel-Mount Connector
10302205D026
- Rated Current: 9 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB 2.0 Type-A Female Receptacle Board/Panel-Mount Connector
10302205D039
- Rated Current: 9 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB Type-C Male Plug Board-Mount Connector
10311024F022
- Rated Current: 5 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 100 MΩ Min
View Details
USBUSB 3.0 Type-A Female Receptacle Board/Panel-Mount Connector
10312109F007
- Rated Current: 1.8 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB 3.0 Type-A Female Receptacle Board/Panel-Mount Connector
10312209A043
- Rated Current: 1.8 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB 3.0 Type-A Female Receptacle Board/Panel-Mount Connector
10312209F038
- Rated Current: 1.8 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB 3.0 Type-A Female Receptacle Board/Panel-Mount Connector
10312218D004
- Rated Current: 2 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 1000 MΩ Min
View Details
USBUSB Type-C Female Receptacle Board/Panel-Mount Connector
10317016B001
- Rated Current: 5 A
- Rated Voltage: 30 V AC
- Insulation Resistance: 100 MΩ Min
View Details
Additional I/O Families For RFQ
More USB, HDMI, SATA, and power connector records for RFQ discovery
These 55 USB, HDMI, SATA, and power connector families support early selection and inquiry intake. Final drawing revision, specification table, and model configuration can be confirmed during RFQ. This includes 0 additional legacy USB records that were not part of the original ammunition map.
Drawing on request: 55Specs to confirm: 0Model details to confirm: 0Legacy USB: 0
Power Connector Board-MountEQT190500Drawing available on requestNew Products Connector Board-MountHQT160910Drawing available on requestNew Products Connector Board-MountHQT160911Drawing available on requestPower 3 Female Receptacle Board/Panel-Mount ConnectorEQT180900Drawing available on requestUSB Type-C Female Receptacle Board/Panel-Mount ConnectorESP190600Drawing available on requestUSB 3.0 Type-A 9-Contact Female Receptacle Right-Angle Connector10312209XXXXDrawing available on requestUSB 3.0 Type-A 9-Contact Female Receptacle Right-Angle Connector10312418XXXXDrawing available on requestHDMI Type-A Male PlugA121902-A-XX-XDrawing available on requestHDMI Type-A Male PlugA121903-C-XX-TDrawing available on requestHDMI Type-A Male PlugA121903-D-XX-XDrawing available on requestHDMI Type-A Male PlugA121904-C-XX-TDrawing available on requestHDMI Type-A Male PlugA121907-A-XX-TDrawing available on requestHDMI Type-A Male PlugA121909-D-XX-TDrawing available on requestHDMI Type-A Male PlugH12903-G-WDrawing available on requestHDMI Type-A Male PlugK120902-G-ON-ADrawing available on requestHDMI Type-A Male PlugK121902-C-ON-CDrawing available on requestHDMI Type-A Female ReceptacleA119A3-J-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA119E1-D-XX-TDrawing available on requestHDMI Type-A Female ReceptacleA1119A3-A-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA1119C3-A-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA1119J1-A-XX-TDrawing available on requestHDMI Type-A Female ReceptacleA1119J1-H-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111910-E-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111911-A-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111912-A-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111917-D-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111922-C-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111925-C-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111925-E-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111929-G-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111946-A-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111946-F-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111972-E-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111988-B-XX-XDrawing available on requestHDMI Type-A Female ReceptacleA111988-F-XX-XDrawing available on requestHDMI Type-C Mini HDMI Male PlugA141909-A-XX-TDrawing available on requestHDMI Type-C Mini HDMI Male PlugA141909-B-XX-TDrawing available on requestHDMI Type-C Mini HDMI Male PlugA141909-C-XX-TDrawing available on requestHDMI Type-C Mini HDMI Male PlugA141912-C-XX-TDrawing available on requestHDMI Type-C Mini HDMI Male PlugK141909-A-0N-CDrawing available on requestHDMI Type-C Mini HDMI Male PlugK141909-A-XX-DDrawing available on requestHDMI Type-C Mini HDMI Female ReceptacleA131903-B-XX-RDrawing available on requestHDMI Type-C Mini HDMI Female ReceptacleA131903-A-XX-RDrawing available on requestHDMI Type-D Micro HDMI Male PlugA161902-A-XX-TDrawing available on requestHDMI Type-D Micro HDMI Male PlugH161902-A-ADrawing available on requestHDMI Type-D Micro HDMI Male PlugK161902-A-0N-BDrawing available on requestHDMI Type-D Micro HDMI Male PlugK161902-A-0N-CDrawing available on requestHDMI Type-D Micro HDMI Female ReceptacleA151901-B-XX-RDrawing available on requestHDMI Type-D Micro HDMI Female ReceptacleA151902-B-XX-RDrawing available on requestHDMI Type-D Micro HDMI Female ReceptacleA151903-F-XX-RDrawing available on requestUSB 2.0 Type-A 5P Male Plug Cable-End Connector29103G00075Drawing available on requestSATA 7P ConnectorSATA03Drawing available on requestUSB 3.0 Type-A 9-Contact Female Receptacle Vertical Connector10316109xxxxDrawing available on requestUSB 3.0 Type-A 9-Contact Female Receptacle Right-Angle Connector10316209xxxxDrawing available on requestUSB Type-A Female Receptacle Right-Angle Connector10312209F048Drawing available on request
Technical Specifications
| Parameter | Specification |
|---|---|
| Type-C Configurations | 6-pin, 16-pin, 24-pin, male, receptacle, SMT, DIP, vertical, offset, waterproof |
| Data Rate (USB-C) | Up to 40 Gbps (USB4) |
| Data Rate (HDMI) | Up to 48 Gbps (HDMI 2.1) |
| Voltage Rating | 5V / 12V / 20V (USB PD) |
| Current Rating | Up to 5A standard USB-C; custom high-current Type-C programs available |
| Mount Type | SMT, DIP, Mid-mount, Through-hole |
| Mating Cycles | 10,000+ (USB-C) |
| Operating Temperature | -40°C to +85°C |
| Compliance | USB-IF, HDMI Forum, VESA certified |
Applications
Consumer Electronics
USB-C and HDMI connectors for smartphones, tablets, laptops, TVs, and gaming consoles.
Industrial Equipment
Ruggedized USB and display connectors for HMI panels, industrial PCs, and test equipment.
Medical Devices
High-reliability I/O connectors for patient monitors, diagnostic imaging, and medical-grade displays.
Automotive Infotainment
USB-C and HDMI connectors for in-vehicle infotainment, rear-seat entertainment, and head units.
Related Product Categories
Why Choose CZT I/O Connectors?
CZT is a USB-IF and HDMI Forum authorized connector manufacturer with precision high-speed stamping and automated assembly lines. Our USB Type-C, HDMI, and DisplayPort connectors pass rigorous signal integrity testing for reliable high-speed data and video transmission.
