A141909-A-XX-T HDMI Type-C Mini HDMI Male Plug
Model:A141909-A-XX-T
HDMI Type-C Mini HDMI Male Plug (A141909-A-XX-T) is organized for HDMI connector selection. Use this record to confirm interface, pin count, gender, mounting orientation, shell construction, and the current drawing revision before sampling. Electrical ratings, insulation resistance, withstand voltage, contact resistance, and durability fields are cleaned for model-to-model comparison where source data is available.
Key Features
- Mini HDMI Type-C plug format for compact cable assemblies
- 19-contact HDMI interface in a smaller mating profile than Type-A
- Cable-end plug style for portable and space-limited equipment
- Shielded shell construction supports signal integrity and EMI control
- Final plating, cable OD, and termination details confirmed during RFQ
Key Specifications
- Interface: HDMI Type-C (Mini HDMI)
- Gender: male plug
- Product style: Mini HDMI cable plug
- Contact layout: HDMI 19-contact family
- +3 more specs below
Request drawing: This product has migrated product identity and specification coverage, but the photo and drawing should be confirmed with sales before sampling.
HDMI Type-C Mini HDMI Male Plug Specifications
InterfaceHDMI Type-C (Mini HDMI)
Gendermale plug
Product styleMini HDMI cable plug
Contact layoutHDMI 19-contact family
Drawing statusrequest drawing during RFQ
Asset statusimage placeholder; request photo during RFQ
RFQ checkconfirm plating, shell style, mounting or cable termination, packaging, and drawing revision
Typical Applications
Portable display and camera HDMI cable assemblies
Compact industrial vision and inspection equipment
Mobile media devices using Mini HDMI outputs
Embedded AV modules with limited panel space
OEM signal cable programs requiring Mini HDMI mating
Frequently Asked Questions
Is A141909-A-XX-T a HDMI Type-C (Mini HDMI) connector?
Yes. The old-site product title identifies this item as HDMI C Plug, and CZT lists it as a HDMI Type-C Mini HDMI Male Plug for HDMI interface programs. Request the current drawing during RFQ to confirm footprint, shell, and termination details.
Can CZT provide the mechanical drawing for this HDMI connector?
This migrated record does not include a local downloadable PDF. Contact CZT with the model number and application details so the sales and engineering team can confirm the correct drawing revision for RFQ review.
Which details should be confirmed before sampling?
Confirm mating interface, mounting or cable termination style, contact plating, shell finish, packaging, and the latest drawing revision before sample release or mass-production approval.
HDMI Type-C Mini HDMI Male Plug Details
CategoryI/O Connectors
SubcategoryHDMI Series
Model NumberA141909-A-XX-T
Naming TemplateUSB/I/O: Interface + Pin Count + Gender + Mount/Orientation + Family
InterfaceHDMI Type-C Mini HDMI
Pin Count19-Contact
GenderMale Plug
Mount / OrientationCable-End
BrandCZT
OriginChina
Drawing StatusRequest drawing
