Industrial / Precision Die Casting
Alloy Housing
Precision die-cast alloy housing designed to enclose and protect electronic assemblies in demanding industrial and commercial environments. Produced from high-strength aluminum or zinc alloy, the housing offers good thermal conductivity, EMI shielding, and corrosion resistance. Suitable for power supplies, motor drives, communication modules, and industrial control enclosures.
Key Features
- Precision die-cast alloy construction with tight dimensional tolerances
- Rigid, lightweight enclosure suitable for demanding industrial environments
- Integrated interface features for accurate PCB and module mounting
- Excellent EMI shielding performance inherent to metal alloy construction
- Surface finish options available to meet corrosion resistance requirements
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Alloy Housing Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Electronic control unit (ECU) enclosures in automotive systems
Industrial sensor and transmitter module housings
Power supply and converter module enclosures
Communication module housings for harsh environments
Precision instrument chassis and structural enclosures
Frequently Asked Questions
What alloy materials are available for this die-cast housing?
CZT's die-cast housings are typically produced in aluminum alloy or zinc alloy, selected based on the application's requirements for weight, strength, thermal conductivity, and machinability. Contact CZT with your mechanical and thermal specifications to confirm the appropriate alloy grade.
What dimensional tolerances can be achieved with precision die casting?
CZT's precision die casting process achieves tolerances suitable for direct assembly without secondary machining in most cases. Typical dimensional tolerances are ±0.1 mm or better depending on feature geometry. Critical interface dimensions can be held to tighter tolerances with post-cast machining.
Can custom surface finishes be applied to the alloy housing?
Yes. Surface treatment options include anodizing, powder coating, electroplating, and chromate conversion coating, depending on the base alloy. CZT can advise on the most suitable finish for your corrosion resistance, aesthetics, and EMI shielding requirements.
Alloy Housing Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
