Industrial / Precision Die Casting
Alloy Housing 2
Precision die-cast alloy housing engineered for applications requiring a combination of structural strength and dimensional accuracy in a compact form factor. The alloy construction offers inherent EMI attenuation and effective heat dissipation for enclosed electronics. Typical applications include networking hardware enclosures, automotive electronics, and industrial instrumentation.
Key Features
- Engineered for applications combining structural strength with dimensional precision
- Die-cast alloy process ensures repeatable geometry across high-volume production
- Supports complex internal features including ribs, bosses, and mounting inserts
- Thermal conductivity of alloy substrate aids passive heat dissipation
- Compatible with secondary machining for critical tolerance interfaces
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Alloy Housing 2 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
High-precision optical and sensor module housings
Servo drive and motion control enclosures
RF module and antenna housing assemblies
Medical device structural enclosure components
Aerospace ground support equipment electronic housings
Frequently Asked Questions
What level of structural strength can be expected from this die-cast housing?
Alloy die-cast housings provide substantially higher tensile and yield strength than injection-molded plastic. Aluminum alloy variants typically achieve tensile strength of 200–300 MPa depending on alloy grade, making them suitable for applications with significant mechanical load or vibration exposure.
Is secondary CNC machining available for critical interface surfaces?
Yes. CZT offers post-cast CNC machining for sealing surfaces, connector interfaces, and precision mounting features that require tighter tolerances than die casting alone can achieve. This is recommended for applications with IP sealing requirements or precision optical alignment needs.
Can this housing be designed to meet specific IP ingress protection ratings?
Die-cast alloy housings can be designed with machined sealing grooves and gasket interfaces to achieve IP54 through IP67 ratings when combined with appropriate sealing components. CZT engineering can assist with seal groove geometry and gasket material selection during the design phase.
Alloy Housing 2 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
