Industrial / Precision Die Casting
Alloy Housing 3
High-precision die-cast alloy housing designed to provide durable mechanical protection and thermal management for sensitive electronic assemblies. Tight casting tolerances support reliable assembly with mating components and reduce the need for post-machining. Well suited for use in power conversion equipment, RF modules, and ruggedized industrial devices.
Key Features
- High-precision die casting for durable mechanical protection of sensitive electronics
- Integrated thermal management features support passive heat dissipation
- Tight dimensional control ensures consistent assembly fit across production batches
- Alloy construction provides inherent EMI shielding for sensitive circuitry
- Surface treatment options available for enhanced corrosion and wear resistance
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Alloy Housing 3 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Sensitive analog and RF electronics shielding enclosures
Industrial temperature and pressure sensor housings
Power electronics module thermal management enclosures
Automotive ADAS sensor and camera module housings
Precision measurement instrument structural housings
Frequently Asked Questions
How does this housing support thermal management for heat-generating electronics?
The alloy substrate's thermal conductivity — typically 90–160 W/m·K for aluminum alloys — allows heat generated by internal components to conduct through the housing walls and dissipate to the surrounding environment. External fin features or heat sink interfaces can be incorporated into the die-cast design to enhance thermal performance.
What inspection and quality control processes are applied to these housings?
CZT applies dimensional inspection using CMM or gauging fixtures, visual inspection for surface defects, and where specified, pressure or leak testing for sealed enclosures. First-article inspection reports are available, and ongoing production sampling follows agreed control plans.
Can internal shielding partitions be integrated into the die-cast design?
Yes. Internal walls, compartments, and shielding ribs can be incorporated into the die-cast tool design to provide compartmentalization or additional EMI isolation between circuit sections. This eliminates the need for separate shielding components and reduces assembly steps.
Alloy Housing 3 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
