E59190800 59 2X1 SLED Crimp Pin Socket
Model:E59190800
The 59 2X1 SLED is a dual-row single-column RJ45 crimp pin socket with an integrated LED, designed for through-board crimp termination that eliminates soldering in high-volume assembly. Its compact footprint supports dense port configurations on backplane and carrier boards. Typical uses include multi-port network switches, industrial Ethernet hubs, and server I/O panels.
Key Features
- Dual-row single-column crimp pin design enables through-board LED light piping
- Integrated LED simplifies status indication without separate discrete components
- Crimp termination provides consistent contact force and repeatable assembly
- Through-board mounting ensures mechanical stability under cable mating loads
- Compact 2×1 layout suits high-density port arrays on backplane designs
Key Specifications
- Product family: modular socket
- Port / layout: 2x1
- Pin / contact count: confirm from drawing
- Mounting / option notes: crimp-pin, LED option
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
59 2X1 SLED Crimp Pin Socket Specifications
Product familymodular socket
Port / layout2x1
Pin / contact countconfirm from drawing
Mounting / option notescrimp-pin, LED option
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusold-site product image available
RFQ checkconfirm drawing revision, mating connector, PCB thickness or panel cutout, plating thickness, LED / light-pipe option, shielding, packaging, and sample requirement
Typical Applications
Network switch backplanes with per-port LED status
Server rack management cards with crimp-pin RJ45 ports
Telecom line cards requiring high-density port arrays
Industrial Ethernet modules with integrated visual indicators
High-cycle-count applications benefiting from crimp reliability
Frequently Asked Questions
What is the benefit of crimp pin termination over standard press-fit or solder in the 59 series?
Crimp termination delivers a gas-tight, cold-weld connection that resists vibration, thermal cycling, and oxidation better than solder in many industrial environments. It also enables faster, more consistent assembly in automated production lines without soldering equipment.
How does the integrated LED in the 59 2X1 SLED route light through the board?
The LED is positioned within the connector body and aligned with the through-board cavity. Light is emitted downward or sideways through the PCB opening to a light pipe or panel indicator. This eliminates the need for a separate LED component and associated routing.
Is the 59 2X1 SLED compatible with standard RJ45 patch cables?
Yes, the mating interface conforms to the 8P8C RJ45 standard and accepts standard Cat5e/Cat6 patch cables. The crimp pin termination is on the PCB side only and does not affect plug compatibility at the mating face.
59 2X1 SLED Crimp Pin Socket Details
CategoryNew Products
Model NumberE59190800
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
