FAKRA Dual-Port Male Horizontal PCB-Mount Connector, 8mm Pitch
FAKRA Dual-Port Male Horizontal PCB-Mount Connector, 8mm Pitch is a CZT automotive connector record prepared for RFQ discovery from the legacy catalog. It has local product imagery and old-site source context, but no local PDF drawing in the archive. Use this page to request the latest drawing and confirm FAKRA automotive coaxial connector, confirm from drawing, male side referenced, horizontal PCB-mount, 8mm pitch reference, vehicle location, sealing target, plating, keying, and sample requirements before quotation.
Key Features
- RFQ-ready FAKRA automotive coaxial connector record with local old-site product image
- Contact or pin-count reference: confirm from drawing
- Mating reference: male side referenced
- Mounting or orientation reference: horizontal PCB-mount, 8mm pitch reference
- Request Drawing workflow for latest drawing revision, mating interface, plating, sealing, and sample confirmation
Key Specifications
- Product family: FAKRA automotive coaxial connector
- Contact / pin count: confirm from drawing
- Mating reference: male side referenced
- Mounting / orientation: horizontal PCB-mount, 8mm pitch reference
- +4 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
FAKRA Dual-Port Male Horizontal PCB-Mount Connector, 8mm Pitch Specifications
Product familyFAKRA automotive coaxial connector
Contact / pin countconfirm from drawing
Mating referencemale side referenced
Mounting / orientationhorizontal PCB-mount, 8mm pitch reference
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusold-site product image available
RFQ checkconfirm mating part, vehicle location, signal type, sealing target, plating, keying / color coding, cable or PCB interface, and drawing revision
Publication boundaryno certification, bandwidth, IP-rating, or high-voltage claim is made until customer drawing and specification are confirmed
