Industrial / Precision Die Casting
Heat Dissipation Component 3
Die-cast thermal management component designed to efficiently conduct and dissipate heat generated by densely packed electronic circuits. Precision casting ensures consistent fin geometry and base thickness for predictable thermal performance across production volumes. Suitable for inverters, servo drives, RF amplifiers, and other heat-sensitive industrial electronics.
Key Features
- Die-cast thermal management component for densely packed electronic assemblies
- Optimized geometry conducts and dissipates heat from multiple heat sources
- High-pressure die casting delivers consistent wall thickness and fin definition
- Lightweight aluminum construction minimizes system weight without sacrificing thermal performance
- Compatible with forced-air and natural convection cooling configurations
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Heat Dissipation Component 3 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Multi-chip power module cooling in industrial drives and inverters
Server and networking switch thermal management for dense board layouts
Automotive power electronics requiring compact, lightweight heat spreaders
Renewable energy inverter thermal management in outdoor enclosures
High-density embedded computing modules with limited airflow clearance
Frequently Asked Questions
How does die casting compare to extrusion for this type of thermal component?
Die casting allows more complex three-dimensional geometries — including integrated mounting features, variable fin heights, and undercuts — that extrusion cannot produce. This makes it preferable for densely packed assemblies where the thermal component must conform to irregular component layouts or enclosure shapes.
What is the typical thermal resistance range for this component?
Thermal resistance depends on fin geometry, surface area, airflow conditions, and interface material. CZT can provide simulation data or measured thermal resistance values for specific configurations. Custom fin pitch and density can be adjusted at the tooling stage to meet target junction-to-ambient thermal resistance.
Is this component suitable for outdoor or harsh environment installations?
With appropriate surface treatment such as anodizing or chromate conversion coating, the die-cast aluminum component provides adequate corrosion resistance for outdoor and industrial environments. For salt spray or high-humidity applications, additional protective coatings can be specified during the ordering process.
Heat Dissipation Component 3 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
