Industrial / Precision Die Casting
Heat Sink
Precision die-cast heat sink providing passive thermal management for electronic components through an extended fin array that maximizes convective heat dissipation. The aluminum alloy construction combines low weight with high thermal conductivity for effective cooling in space-constrained designs. Widely used in power modules, industrial control boards, and embedded computing platforms.
Key Features
- Extended fin array maximizes surface area for passive thermal dissipation
- Precision die-cast construction ensures uniform fin pitch and structural integrity
- Passive cooling design eliminates fan noise and mechanical failure risk
- Mounting base machined flat for low thermal resistance interface contact
- Scalable fin count and height to match specific thermal load requirements
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Heat Sink Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Passive cooling of voltage regulators and power semiconductors on PCBs
LED high-bay and street lighting fixture thermal management
Industrial control panel components requiring fanless heat dissipation
Embedded computing systems in sealed enclosures without forced airflow
RF power amplifier modules requiring low-profile passive heat sinks
Frequently Asked Questions
What fin geometries are available for this die-cast heat sink?
CZT offers straight fin, cross-cut fin, and pin fin configurations depending on airflow direction and space constraints. Straight fins suit unidirectional airflow; pin fins perform better in omnidirectional or low-airflow environments. Custom fin geometry can be incorporated into the die tooling for OEM orders.
How is the mounting base surface prepared for thermal interface materials?
The mounting base is machined after casting to achieve the flatness and surface roughness required for effective thermal interface material contact. This minimizes air gaps between the heat sink and component package, directly reducing thermal resistance at the critical junction-to-heat-sink interface.
What is the minimum order quantity for custom heat sink tooling?
MOQ for custom die-cast heat sink tooling varies based on part complexity and die size. CZT typically works with OEM customers to amortize tooling costs over production volumes. Contact CZT's sales team with your thermal specifications and target volume for a tooling and unit price quotation.
Heat Sink Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
