JDD240870242 Single-Port PCB Mount ICM RJ45 Integrated Magnetics Jack
Model:JDD240870242
Single-Port PCB Mount ICM RJ45 Integrated Magnetics Jack (JDD240870242) is organized for RJ45 and modular-jack RFQ review. Use this record to confirm single-port layout, PCB-mount orientation, icm configuration, and the rj45 integrated magnetics jack drawing before sample release. Key electrical items such as current rating, voltage rating, insulation resistance, dielectric strength, and contact resistance are normalized below for faster comparison.
Key Features
- 8-port 1000BASE-T ICM with integrated transformer per port
- IEEE 802.3ab compliant for full-duplex Gigabit Ethernet
- UL94V-0 flame retardant housing with LCP, PBT, PA46, PA66 options
- Gold-plated phosphor bronze terminals for reliable signal integrity
- Optimized for mid-density switch and gateway PCB layouts
Key Specifications
- Rated Current: 0.6 A
- Rated Voltage: 57 V DC
- Insulation Resistance: 500 MΩ Min
- Housing Material: LCP / PBT / PA46 / PA66 / ABS / PC options
- +1 more specs below
Single-Port PCB Mount ICM RJ45 Integrated Magnetics Jack Specifications
Rated Current0.6 A
Rated Voltage57 V DC
Insulation Resistance500 MΩ Min
Housing MaterialLCP / PBT / PA46 / PA66 / ABS / PC options
Flame RatingUL94V-0 / UL94V-1 options
Typical Applications
8-port Gigabit managed and unmanaged switches
Industrial Ethernet edge switches and field controllers
Network video recorder (NVR) and IP camera hubs
Embedded computing platforms with multi-port LAN
Telecom CPE and broadband gateway equipment
Frequently Asked Questions
How does the 8-port ICM compare to using discrete RJ45 jacks with external transformers?
The JDD240870242 integrates eight jacks and eight transformers in one component, reducing PCB area by up to 40%, cutting assembly complexity, and providing pre-matched transformer-to-jack performance that is difficult to achieve with discrete layouts.
What flame retardancy standard does this module meet?
The housing meets UL94V-0, the most stringent standard in the UL94 series, meaning the material self-extinguishes within 10 seconds after flame removal. This is required for most networking and industrial equipment safety certifications.
Can the housing material be customized for specific reflow soldering profiles?
Yes. LCP and PA46 variants are recommended for lead-free reflow processes due to their higher heat deflection temperatures. PBT and PA66 are suitable for wave soldering or lower-temperature reflow profiles. Specify your process requirements when ordering.
Single-Port PCB Mount ICM RJ45 Integrated Magnetics Jack Details
CategoryRJ45/Ethernet
SubcategoryRJ45+Transformer
Model NumberJDD240870242
Naming TemplateRJ45: Port Count + Orientation + Shield/LED + Family
Port CountSingle-Port
OrientationPCB Mount
Shield / LEDICM
FamilyRJ45 Integrated Magnetics Jack
BrandCZT
OriginChina
Drawing StatusDownloadable datasheet
