SC to FC Single-Mode Fiber Optic Patch Cable, 5 m Fiber Patch Cable Single-Mode
Model:SC to FC Single-Mode Fiber Optic Patch Cable, 5 m
SC to FC Single-Mode Fiber Optic Patch Cable, 5 m Fiber Patch Cable Single-Mode (SC to FC Single-Mode Fiber Optic Patch Cable, 5 m) is a CZT cable assembly record prepared for OEM RFQ intake. The page separates Connector A, Connector B, cable type, and plating/material so buyers can quickly confirm length, wire gauge, shielding, jacket, labeling, and packaging requirements. Continuity, insulation, conductor resistance, insertion/extraction force, service life, and temperature data are normalized in the specification table when available.
Key Features
- SC-to-FC single-mode fiber optic patch cable, 5-meter length
- Short-term tensile load rating of 100 N; long-term rating of 60 N
- Dynamic minimum bending radius of 50 mm; static minimum 30 mm
- Single-mode fiber optimized for low-loss long-distance signal transmission
- Robust jacket construction for industrial wire harness integration
Key Specifications
- mechanical characteristics
- Allowable Tensile Force (N): short-term:100 long-term:60
- Minimum Bending Radius (mm): dynamic:50 static:30 2.environmental performance:
- Environmental Performance:
- +4 more specs below
SC to FC Single-Mode Fiber Optic Patch Cable, 5 m Fiber Patch Cable Single-Mode Specifications
mechanical characteristics
Allowable Tensile Force (N)short-term:100 long-term:60
Minimum Bending Radius (mm)dynamic:50 static:30 2.environmental performance:
Environmental Performance
Operating Temperature-20 °C to 60 °C
Storage Temperature-20 °C to 60 °C
Storage Time12 months
Transmission Characteristics
Typical Applications
Fiber optic patch panel interconnects in data centers
Industrial automation network fiber backbone connections
Telecommunications equipment SC-to-FC cross-connects
CCTV and security system fiber optic signal runs
Test bench fiber optic signal routing and measurement setups
Frequently Asked Questions
What is the maximum tensile force this fiber optic cable can withstand?
The cable is rated for a short-term tensile force of 100 N and a long-term sustained tensile force of 60 N. Exceeding these limits risks fiber breakage or connector damage. For installations with higher mechanical stress, consult CZT for armored cable options.
What is the minimum bending radius for this SC-to-FC patch cable?
The dynamic minimum bending radius is 50 mm, applicable during installation and movement. The static minimum bending radius is 30 mm for fixed installations. Maintaining these limits prevents microbend-induced signal loss and physical fiber damage.
Is this cable suitable for outdoor or harsh industrial environments?
This cable is designed for industrial wire harness applications and offers environmental performance suited to controlled industrial settings. For outdoor or extreme-environment deployments, confirm jacket material and environmental ratings with CZT to ensure compatibility with your installation conditions.
What insertion loss can be expected from the SC and FC connectors?
Typical insertion loss for single-mode SC and FC connectors is ≤0.3 dB per connector. Actual values depend on fiber alignment and end-face polish quality. CZT can provide test reports for specific cable assemblies upon request.
SC to FC Single-Mode Fiber Optic Patch Cable, 5 m Fiber Patch Cable Single-Mode Details
CategoryIndustrial
SubcategoryWire Harness
Model NumberSC to FC Single-Mode Fiber Optic Patch Cable, 5 m
Naming TemplateWire Harness: Connector A to Connector B + Cable Type + Plating/Material
Connector ASC
Connector BFC Single-Mode Fiber Optic Patch Cable, 5 m
Cable TypeFiber Patch Cable
Plating / MaterialSingle-Mode
BrandCZT
OriginChina
Drawing StatusDownloadable datasheet
