Precision Connector Assembly 10
Die cast precision connector assembly engineered for reliable signal and power transmission in demanding industrial settings. Its robust construction ensures stable contact retention under vibration and thermal cycling. Well suited for use in manufacturing equipment, robotics, and field-installed control systems.
Key Features
- Die cast construction ensures repeatable dimensional accuracy at scale
- Engineered for reliable signal and power transmission in harsh environments
- High mechanical integrity suitable for demanding industrial duty cycles
- Precision tooling delivers consistent part geometry across production batches
- Designed for drop-in compatibility with standard industrial connector interfaces
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 10 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Heavy industrial equipment power and signal connector interfaces
Robotics and motion control system connector assemblies
Rail and transportation equipment connector housings
Energy sector control and monitoring system interconnects
High-vibration environments requiring mechanically robust connector bodies
Frequently Asked Questions
What distinguishes Precision Connector Assembly 10 from Assembly 1?
Both assemblies use the same precision die casting process and quality standards, but differ in form factor, pin configuration, or mechanical interface geometry. Assembly 10 is engineered for specific industrial applications requiring its unique dimensional profile. Contact CZT with your interface requirements to confirm the correct assembly variant.
Are these die cast assemblies suitable for high-vibration environments?
Yes. Die cast metal connector assemblies offer significantly higher resistance to vibration-induced loosening and mechanical fatigue compared to plastic housings. The inherent rigidity of the cast alloy structure maintains connector alignment and contact integrity under continuous vibration loads typical in industrial, rail, and heavy equipment applications.
What is the typical lead time for high-volume orders of die cast connector assemblies?
Lead times depend on order volume, tooling status, and surface finish requirements. For existing tooled parts, standard production lead times typically range from 4 to 8 weeks. New tooling development adds additional lead time. Contact CZT's sales team with your volume forecast and delivery schedule for a firm quotation.
Precision Connector Assembly 10 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
