Industrial / Precision Die Casting
Precision Connector Assembly 11
Precision connector assembly featuring a die cast enclosure that provides structural rigidity and EMI shielding for sensitive signal lines. The design supports secure mating and repeated connect-disconnect cycles without degradation. Commonly deployed in industrial instrumentation, PLC systems, and machine tool interfaces.
Key Features
- Die cast enclosure delivers structural rigidity under mechanical stress
- Integrated EMI shielding protects sensitive signal integrity
- Precision-machined contact cavities ensure repeatable mating alignment
- Compact form factor suits space-constrained sensor installations
- Corrosion-resistant alloy construction extends service life in harsh environments
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 11 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial sensor wiring in automated manufacturing lines
Control cabinet signal distribution for PLCs and I/O modules
Robotics joint feedback and encoder cable termination
Machine vision system camera and lighting interconnects
Process instrumentation field device wiring assemblies
Frequently Asked Questions
What EMI shielding effectiveness does the die cast enclosure provide?
The die cast zinc or aluminum alloy enclosure provides continuous 360° shielding continuity when mated, typically achieving attenuation levels suitable for industrial environments with moderate to high electromagnetic interference. Exact dB ratings depend on frequency range and should be confirmed with CZT's engineering team for your specific application.
Is this assembly compatible with standard industrial sensor cable diameters?
Yes, the assembly is designed to accommodate common industrial sensor cable outer diameters. Strain relief and cable entry options can be configured to match your cable spec. Contact CZT for custom cable entry sizing if your application uses non-standard cable dimensions.
Can the die cast housing be grounded to the machine chassis?
Yes, the die cast metallic housing supports chassis grounding via a dedicated grounding lug or through the mounting hardware. This is recommended in high-noise environments to ensure the EMI shielding is properly referenced to system ground.
Precision Connector Assembly 11 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
Related Products
Need a Custom Solution?
CZT offers OEM/ODM services with flexible MOQ. Contact our engineering team for custom connector solutions.
