Industrial / Precision Die Casting
Precision Connector Assembly 12
Industrial-grade precision connector assembly with a die cast body offering dimensional consistency across high-volume production runs. Designed to maintain reliable electrical continuity in environments with mechanical stress or temperature variation. Suitable for power distribution boards, servo drives, and automated assembly lines.
Key Features
- Die cast body ensures dimensional consistency across high-volume production runs
- Industrial-grade materials rated for continuous duty in factory environments
- Tight tolerance contact positioning minimizes insertion force variation
- Robust locking mechanism prevents accidental disconnection under vibration
- Scalable design supports multi-conductor configurations for complex wiring
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 12 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
High-volume automotive assembly line wiring harness termination
Industrial motor drive and inverter control signal connections
Conveyor system power and feedback cable assemblies
Packaging machinery multi-axis motion control wiring
Factory automation panel-to-field device interconnects
Frequently Asked Questions
How does die cast construction improve dimensional consistency compared to plastic housings?
Die casting produces metal housings with tighter dimensional tolerances than injection-molded plastics, typically holding ±0.1mm or better on critical mating features. This consistency is critical in high-volume production where connector interchangeability across thousands of assemblies is required to maintain line efficiency.
What quality controls are applied during high-volume production of this assembly?
CZT applies in-process dimensional inspection, contact insertion force testing, and electrical continuity verification at key production stages. Statistical process control (SPC) is used to monitor critical dimensions, ensuring batch-to-batch consistency for OEM customers with strict incoming quality requirements.
Are custom pin counts or contact arrangements available for OEM orders?
Yes, CZT supports custom contact configurations for OEM programs. Minimum order quantities apply for tooling amortization on custom die cast housings. CZT's engineering team can review your schematic and propose an optimized contact layout during the design phase.
Precision Connector Assembly 12 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
