Precision Connector Assembly 13
Precision die cast connector assembly built to deliver stable interconnection performance in compact industrial enclosures. The cast housing provides a secure mounting interface and protects internal contacts from contamination. Frequently used in conveyor systems, sensor networks, and industrial communication backplanes.
Key Features
- Compact die cast housing designed for space-constrained industrial enclosures
- Stable interconnection performance maintained across thermal cycling conditions
- Precision contact alignment reduces signal degradation in dense wiring layouts
- Robust shell withstands panel mounting torque without deformation
- Available in multiple circuit counts to suit varied I/O requirements
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 13 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Compact control enclosures for distributed I/O systems
Embedded industrial computing module signal interfaces
Small-form-factor servo drive feedback connector assemblies
DIN rail mounted terminal block to field device wiring
Medical-grade industrial equipment internal signal routing
Frequently Asked Questions
What are the minimum bend radius requirements for cables used with this assembly?
Minimum bend radius depends on the cable type and outer diameter used with the assembly. CZT recommends following the cable manufacturer's specified minimum bend radius and using the assembly's integrated strain relief to prevent stress concentration at the cable entry point, particularly in dynamic flex applications.
How does this assembly perform in thermal cycling environments?
The die cast metallic housing and precision contact system are designed to maintain stable contact resistance through repeated thermal cycles. The coefficient of thermal expansion of the housing alloy is matched to minimize differential expansion stress on contacts, preserving mating integrity across typical industrial temperature ranges of -25°C to +85°C.
Can this connector assembly be panel-mounted in sealed enclosures?
Yes, panel-mount versions are available with optional sealing gaskets to achieve IP54 or higher ingress protection ratings when installed in sealed enclosures. Confirm the required IP rating with CZT at time of order to ensure the correct sealing hardware is included.
Precision Connector Assembly 13 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
