Industrial / Precision Die Casting
Precision Connector Assembly 14
Heavy-duty precision connector assembly manufactured with die casting techniques for tight tolerances and repeatable fit. Designed to handle both signal and low-voltage power connections within a single ruggedized housing. Applicable in energy management systems, industrial gateways, and process control terminals.
Key Features
- Heavy-duty die cast construction maintains tight tolerances under load
- Repeatable mating geometry supports frequent connect/disconnect cycles
- High contact retention force resists pull-out in vibration-prone installations
- Thick-wall die cast shell provides superior impact resistance
- Precision-formed contacts ensure low and stable contact resistance over time
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 14 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Heavy industrial machinery power and control cable termination
Mining and quarrying equipment electrical interconnects
Construction equipment onboard control system wiring
Steel mill automation and drive system cable assemblies
High-cycle test fixture and automated equipment wiring
Frequently Asked Questions
What mating cycle rating does this heavy-duty assembly support?
The precision die cast housing and contact system are engineered for high mating cycle durability. Standard configurations are rated for a minimum of 500 mating cycles while maintaining contact resistance within specification. Higher cycle ratings are available with enhanced contact plating options — consult CZT for your specific duty cycle requirements.
How are tight tolerances maintained in die casting for heavy-duty applications?
CZT uses high-pressure die casting with precision-machined tooling and post-cast CNC finishing on critical mating surfaces. This process achieves dimensional tolerances of ±0.05mm on contact cavity positions, ensuring consistent pin alignment and mating force even in heavy-duty assemblies subjected to mechanical stress.
Is the assembly rated for use in high-vibration environments such as mining equipment?
Yes, the heavy-duty die cast housing combined with a positive locking mechanism is designed to resist vibration-induced loosening. For extreme vibration profiles, CZT recommends specifying the secondary locking or jackscrew retention option to meet IEC 60068-2-6 vibration test requirements.
Precision Connector Assembly 14 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
