Precision Connector Assembly 15
Precision connector assembly with a die cast frame that ensures accurate pin alignment and long-term mechanical stability. The assembly is optimized for environments requiring consistent electrical performance under load cycling. Common use cases include HVAC control units, industrial sensors, and embedded computing modules.
Key Features
- Die cast frame guarantees accurate pin alignment across all contact positions
- Long-term mechanical stability maintained under continuous operational loads
- Precision cavity geometry minimizes contact skew during blind mating
- Durable alloy construction resists creep and deformation at elevated temperatures
- Modular design allows field-replaceable contact inserts without housing replacement
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 15 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Blind-mate backplane connector assemblies in industrial racks
Automated guided vehicle (AGV) docking station electrical interfaces
CNC machine tool spindle and axis drive wiring
Industrial robot end-of-arm tooling quick-change connectors
Power distribution unit (PDU) output connector assemblies
Frequently Asked Questions
How does the die cast frame maintain pin alignment over the product's service life?
The die cast metallic frame provides a rigid, dimensionally stable contact cavity structure that resists the creep and relaxation seen in polymer housings under sustained load. Combined with precision-machined contact retention features, pin position is maintained within specification throughout the rated service life, even under repeated mating cycles.
Is this assembly suitable for blind-mating applications where visual alignment is not possible?
Yes, the precision die cast frame includes chamfered lead-in geometry on contact cavities and the mating face to guide pin engagement during blind mating. This is particularly valuable in automated docking and backplane applications where mechanical alignment guides control gross positioning but fine contact alignment relies on the connector geometry.
Can contact inserts be replaced in the field without replacing the die cast housing?
Modular versions of this assembly support field-replaceable contact inserts, allowing maintenance teams to replace worn or damaged contacts without discarding the die cast housing. This reduces lifecycle cost in applications with high mating cycles or where contact wear is a known maintenance item.
Precision Connector Assembly 15 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
