Precision Connector Assembly 16
Die cast precision connector assembly designed for secure, low-resistance electrical connections in industrial applications. The rigid housing minimizes connector flex and maintains contact integrity during installation and operation. Suited for use in motor control centers, switchgear assemblies, and industrial power conditioning equipment.
Key Features
- Die cast frame ensures low-resistance electrical connections in industrial use
- Secure locking geometry prevents unintended disconnection under vibration
- Optimized contact surface finish minimizes interface resistance
- Industrial-rated insulation materials support high-voltage isolation
- Compact footprint compatible with high-density panel wiring layouts
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 16 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial power distribution panel connector assemblies
Variable frequency drive (VFD) input and output wiring
Switchgear and circuit breaker control wiring terminations
Battery management system (BMS) cell monitoring connectors
Solar inverter DC and AC side cable assemblies
Frequently Asked Questions
What contact resistance values can be expected from this assembly?
Initial contact resistance for this assembly is typically below 5 mΩ per contact pair under specified mating conditions. The die cast housing maintains contact normal force within design limits, preventing resistance increase due to contact relaxation. Exact values depend on contact plating and current rating — CZT can provide test data for your specification.
What voltage and current ratings are available for this connector assembly?
Standard configurations support working voltages up to 600V AC/DC and current ratings from 10A to 50A per contact depending on contact size and spacing. Higher ratings are available in custom configurations. Always verify derating requirements for elevated ambient temperatures in enclosed panel installations.
Does the locking mechanism meet any industry vibration or shock standards?
The locking geometry is designed and tested to retain mating integrity under vibration profiles consistent with IEC 60068-2-6 and shock profiles per IEC 60068-2-27. Specific test reports are available upon request for customers requiring documented compliance for their end-product certification.
Precision Connector Assembly 16 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
Related Products
Need a Custom Solution?
CZT offers OEM/ODM services with flexible MOQ. Contact our engineering team for custom connector solutions.
