Precision Connector Assembly 17
Precision connector assembly utilizing die cast construction to achieve uniform wall thickness and reliable locking geometry. Engineered for applications where connector misalignment or loosening under vibration is a concern. Widely used in transportation electronics, industrial vehicles, and outdoor control enclosures.
Key Features
- Uniform wall thickness achieved through precision die casting process control
- Reliable locking geometry engineered for consistent engagement force
- Dimensional repeatability supports automated assembly line integration
- Die cast shell provides excellent resistance to torsional and bending loads
- Surface treatment options include chromate conversion and powder coating
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 17 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Automated assembly line robotic tooling electrical interfaces
Industrial IoT gateway and edge device field wiring
Pneumatic valve manifold solenoid connector assemblies
Servo motor feedback and power connector terminations
Industrial Ethernet and fieldbus cable shield termination
Frequently Asked Questions
Why is uniform wall thickness important in a die cast connector housing?
Uniform wall thickness prevents internal porosity, warping, and stress concentrations that can occur in uneven sections during solidification. For connector housings, this translates to consistent dimensional accuracy on mating faces and contact cavities, reliable locking feature geometry, and predictable mechanical performance across the entire production run.
What surface treatment options are available for the die cast housing?
CZT offers chromate conversion coating for corrosion resistance and electrical conductivity, anodizing for aluminum alloy housings, and powder coating for enhanced chemical and abrasion resistance. The appropriate treatment depends on the operating environment — CZT's application engineers can recommend the best option for your installation conditions.
Is this assembly compatible with automated connector insertion equipment?
Yes, the dimensional consistency of the die cast housing makes it well-suited for automated assembly processes. Consistent outer dimensions and locking feature geometry allow reliable pick-and-place and insertion operations. CZT can provide 3D CAD models and dimensional drawings to support integration into your automated assembly line.
Precision Connector Assembly 17 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
