Industrial precision connector assembly with a die cast housing that combines mechanical durability with accurate contact positioning. The design accommodates multi-wire terminations while maintaining a compact overall footprint. Typical applications span factory automation, test and measurement equipment, and distributed I/O systems.
Key Features
- Die cast housing combines mechanical durability with accurate contact positioning
- Precision contact geometry ensures reliable mating in industrial wiring systems
- High-strength alloy construction withstands mechanical abuse in field installations
- Integrated strain relief protects cable terminations from pull and flex loads
- Multiple mounting configurations available for panel, bulkhead, and inline use
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 18 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial control panel field wiring and cabinet interconnects
Crane and hoist control system pendant cable assemblies
Pump and compressor motor control wiring terminations
Rail vehicle onboard electrical system connector assemblies
Offshore and marine industrial equipment wiring harnesses
Frequently Asked Questions
What alloy materials are used in the die cast housing construction?
CZT primarily uses zinc alloy (Zamak series) and aluminum alloy (ADC12 / A380) for die cast connector housings. Zinc alloys offer superior surface finish and tighter tolerances for smaller housings, while aluminum alloys provide a better strength-to-weight ratio for larger assemblies. Material selection is confirmed based on application requirements at the design stage.
How does the integrated strain relief protect cable terminations?
The integrated strain relief clamps the cable outer jacket within the die cast housing, transferring tensile and bending loads from the cable to the housing rather than to the individual conductor terminations. This prevents conductor fatigue and contact loosening in applications where cables are subject to repeated movement, pulling, or vibration.
Is this assembly available in IP-rated versions for outdoor or wet environments?
Yes, IP-rated versions with elastomeric sealing gaskets and sealed cable entry are available, achieving IP65 or IP67 ratings depending on configuration. These are suitable for outdoor installations, wash-down environments, and marine applications. Specify the required IP rating when ordering to ensure correct sealing components are included.
Precision Connector Assembly 18 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
