Industrial / Precision Die Casting
Precision Connector Assembly 19
Precision die cast connector assembly offering consistent mating force and contact alignment for industrial wiring harnesses. The cast alloy body resists deformation under clamping loads and provides a stable grounding path. Used in power electronics assemblies, industrial drives, and high-cycle connector applications.
Key Features
- Consistent mating force across all contact positions ensures reliable engagement
- Precision contact alignment critical for industrial wiring harness integrity
- Die cast housing maintains contact geometry under thermal and mechanical stress
- Optimized contact normal force balances low insertion effort with secure retention
- Compatible with standard industrial wiring harness assembly tooling and processes
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 19 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial wiring harness sub-assembly and termination
Automotive off-highway vehicle electrical system connectors
Agricultural machinery control and sensor wiring harnesses
Material handling equipment multi-circuit cable assemblies
Industrial generator set control and monitoring wiring
Frequently Asked Questions
How is consistent mating force achieved across all contact positions?
Consistent mating force is achieved through precision die cast contact cavity geometry that maintains uniform contact normal force across all positions. CZT's tooling and process controls ensure cavity-to-cavity dimensional variation is minimized, preventing the uneven insertion forces that can cause incomplete mating or contact damage during harness assembly.
What wire gauge range is compatible with this connector assembly?
Standard configurations accommodate wire gauges from 24 AWG to 12 AWG depending on contact size selected. CZT offers multiple contact size options within the same housing family to support mixed wire gauge harnesses. Consult the product datasheet or CZT's engineering team to confirm compatibility with your specific wire gauge and insulation diameter.
Is this assembly compatible with standard harness assembly crimp tooling?
Yes, contacts used in this assembly are designed for use with standard industrial crimp tooling. CZT specifies the recommended crimp tool and die set for each contact size to ensure correct crimp height and pull-out force. Using the specified tooling is required to maintain contact performance and warranty coverage.
Precision Connector Assembly 19 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
