Precision Connector Assembly 2
Precision connector assembly with die cast construction providing a durable interface for multi-conductor industrial cable connections. Designed for straightforward installation while maintaining secure retention under operational stress. Commonly found in building automation systems, industrial lighting controls, and modular machine platforms.
Key Features
- Die cast construction provides durable interface for multi-conductor industrial cables
- Robust housing withstands repeated mating cycles in industrial cable management
- Precision contact arrangement supports high conductor count configurations
- Metallic shell ensures continuous EMI shielding across the mated interface
- Standardized dimensions enable drop-in replacement in existing cable assemblies
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 2 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Multi-conductor industrial control cable field termination
Machine tool axis and spindle multi-circuit cable assemblies
Industrial communication and hybrid power/signal cable interfaces
Process plant instrumentation multi-pair cable connectors
Elevator and escalator control system wiring assemblies
Frequently Asked Questions
What is the maximum conductor count supported in this multi-conductor assembly?
Standard configurations support up to 37 contacts depending on contact size and housing dimensions. Higher conductor counts are available in custom configurations. For mixed signal and power applications, CZT can configure hybrid layouts with different contact sizes within the same die cast housing to optimize circuit density.
How does the die cast housing support EMI shielding in multi-conductor cable assemblies?
The die cast metallic housing provides a continuous conductive shell that, when properly terminated to the cable shield braid, creates a complete Faraday enclosure around the conductor bundle. This prevents both ingress of external EMI and egress of internally generated noise, which is critical in multi-conductor cables carrying mixed signal and power circuits.
Are standardized dimensions maintained for backward compatibility with existing installations?
Yes, CZT maintains dimensional compatibility with widely used industrial connector standards on mating face geometry and panel cutout dimensions. This allows the assembly to serve as a direct replacement in existing installations without modification to panels or mating connectors. Confirm compatibility by providing the existing connector part number or drawing to CZT's sales team.
Precision Connector Assembly 2 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
