Industrial / Precision Die Casting
Precision Connector Assembly 20
Die cast precision connector assembly engineered to support reliable data and power interconnection in space-constrained industrial panels. The housing geometry ensures correct orientation during mating, reducing installation errors. Applicable in programmable controllers, fieldbus networks, and industrial edge computing hardware.
Key Features
- Die-cast housing engineered for reliable data and power interconnection in tight spaces
- Compact form factor optimized for space-constrained industrial enclosures and panels
- High dimensional accuracy ensures consistent mating force and contact alignment
- Robust metallic shell provides EMI shielding and mechanical protection
- Suitable for high-cycle mating applications with stable electrical performance
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 20 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Compact industrial control panels with dense connector layouts
Embedded computing modules requiring reliable board-to-board interconnection
Space-constrained robotics joints and servo drive assemblies
Miniaturized medical diagnostic equipment power and signal routing
Aerospace avionics bays with limited connector footprint requirements
Frequently Asked Questions
What makes this connector assembly suitable for space-constrained installations?
The die-cast housing is engineered to minimize footprint while maintaining full contact integrity. Tight dimensional tolerances allow dense connector placement without sacrificing mating reliability, making it ideal for compact industrial enclosures, embedded systems, and high-density panel designs.
Does the die-cast construction affect EMI performance?
Yes, the metallic die-cast shell provides inherent EMI shielding, reducing radiated interference in sensitive signal environments. This is particularly beneficial in data acquisition systems, motion controllers, and other electronics where signal integrity is critical.
What materials are typically used in the die-cast housing?
Die-cast connector housings are commonly produced from zinc alloy or aluminum alloy, offering a balance of mechanical strength, dimensional stability, and corrosion resistance. Material selection depends on the target environment and required weight constraints.
Precision Connector Assembly 20 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
