Precision Connector Assembly 21
Precision connector assembly produced through die casting for high dimensional repeatability and consistent assembly quality at scale. The robust housing design supports secure cable strain relief and stable contact engagement over extended service life. Suited for use in industrial machinery, renewable energy systems, and process automation equipment.
Key Features
- Die casting process delivers high dimensional repeatability across large production volumes
- Consistent assembly quality reduces field failure rates and rework costs
- Uniform contact geometry ensures predictable insertion and withdrawal forces
- Rigid housing construction withstands mechanical shock and vibration loads
- Compatible with automated assembly lines due to tight part-to-part consistency
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 21 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
High-volume industrial automation equipment requiring consistent connector performance
Automotive electronic control unit harness termination assemblies
Telecommunications infrastructure cabinets with standardized connector interfaces
Power distribution modules in factory floor control systems
Consumer appliance motor drive and sensor interconnection assemblies
Frequently Asked Questions
How does die casting improve dimensional repeatability compared to other manufacturing methods?
Die casting forces molten metal into precision steel molds under high pressure, producing parts with tight tolerances and minimal variation between cycles. This results in connector housings with consistent contact spacing, shell dimensions, and mating interfaces across every production batch.
Is this connector assembly compatible with automated pick-and-place or robotic assembly systems?
Yes. The high dimensional consistency of die-cast parts makes them well-suited for automated assembly. Uniform geometry ensures reliable feeding, orientation, and placement in robotic assembly lines, reducing cycle time and minimizing assembly errors in high-volume production environments.
What quality controls are applied during production?
Production includes dimensional inspection using CMM or optical measurement systems, contact resistance testing, and mechanical pull-force verification. Statistical process control is applied to monitor die casting parameters and maintain consistent output quality across production runs.
Precision Connector Assembly 21 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
