Industrial / Precision Die Casting
Precision Connector Assembly 22
Precision connector assembly manufactured using die casting processes for consistent dimensional accuracy and structural integrity. Designed for reliable electrical and mechanical interconnection in demanding industrial environments. Commonly used in automation equipment, control panels, and industrial machinery where repeatable performance is required.
Key Features
- Die casting manufacturing ensures consistent dimensional accuracy across all housing features
- Structural integrity maintained under repeated mating cycles and mechanical stress
- Precise contact cavity geometry supports accurate pin and socket alignment
- Surface finish options available for corrosion resistance in harsh environments
- Designed for compatibility with standard industrial connector interface specifications
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 22 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial machinery control cabinets requiring dimensionally stable connectors
Precision motion control systems with tight connector alignment tolerances
Railway signaling and control equipment interconnection assemblies
Heavy-duty test and measurement instrument front-panel connectors
Energy management systems in smart grid infrastructure installations
Frequently Asked Questions
What dimensional tolerances can be achieved with die-cast connector housings?
Die casting typically achieves tolerances of ±0.1 mm or tighter on critical dimensions, depending on part geometry and alloy selection. For connector housings, this precision ensures consistent contact pitch, shell alignment, and mating interface geometry across all production units.
How does structural integrity hold up under repeated mating and unmating cycles?
The die-cast metallic housing resists deformation under repeated mechanical loading. Combined with precision-formed contact cavities, the assembly maintains alignment and contact force consistency throughout its rated mating cycle life, which is critical for maintenance-intensive industrial applications.
Are surface treatment options available to improve corrosion resistance?
Yes. Die-cast housings can be finished with electroplated nickel, zinc chromate, or powder coating depending on the operating environment. These treatments extend service life in humid, chemically active, or outdoor industrial environments without compromising dimensional accuracy.
Precision Connector Assembly 22 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
