Industrial / Precision Die Casting
Precision Connector Assembly 23
Die-cast precision connector assembly offering stable contact performance and robust housing construction suited for industrial-grade applications. The precision casting process ensures tight tolerances and uniform part quality across production runs. Typical applications include factory automation systems, power distribution units, and electronic control assemblies.
Key Features
- Stable contact performance maintained across wide temperature and humidity ranges
- Robust die-cast housing construction resists deformation under industrial mechanical loads
- Engineered for demanding industrial environments with exposure to vibration and shock
- Consistent contact resistance values ensure reliable signal and power transmission
- Housing geometry designed for secure panel mounting and strain relief integration
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 23 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial motor drives and variable frequency drive control wiring
Heavy equipment onboard electronics exposed to continuous vibration
Outdoor industrial monitoring stations with environmental exposure
Welding equipment power and control circuit interconnections
Mining and construction machinery electronic control assemblies
Frequently Asked Questions
What operating temperature range is this connector assembly rated for?
Die-cast precision connector assemblies are typically rated for operating temperatures from -40°C to +125°C, depending on contact plating and housing alloy. This range covers most industrial environments including outdoor installations, engine compartments, and high-ambient factory floor applications.
How does the die-cast housing perform under continuous vibration exposure?
The rigid metallic die-cast structure resists resonance and fatigue cracking better than plastic housings under sustained vibration. When combined with proper panel mounting and strain relief, the assembly maintains contact integrity in heavy equipment, compressors, and other high-vibration industrial machinery.
Is the connector assembly suitable for use in dusty or wet industrial environments?
With appropriate sealing accessories or IP-rated mating connectors, the die-cast housing can be deployed in dusty or wet environments. The robust metallic shell provides a reliable sealing surface, and surface treatments further enhance resistance to moisture ingress and corrosion.
Precision Connector Assembly 23 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
