Industrial / Precision Die Casting
Precision Connector Assembly 24
Precision connector assembly produced through industrial die casting, delivering consistent mechanical strength and reliable interconnection performance. Its construction supports secure mating and long service life under repeated use. Well suited for use in industrial control systems, instrumentation, and embedded electronic assemblies.
Key Features
- Industrial die casting delivers consistent mechanical strength across all production units
- Reliable electrical interconnection performance under sustained load and thermal cycling
- Precision-formed contact cavities maintain correct pin positioning during assembly
- High-strength housing alloy resists cracking under torque and panel mounting stress
- Designed for long service life in continuous-duty industrial operating conditions
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 24 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial power supply units requiring robust output connector assemblies
PLC and DCS control system field wiring termination points
Conveyor and material handling system drive interconnections
Hydraulic and pneumatic control valve solenoid wiring assemblies
Switchgear and circuit breaker panel wiring interface connectors
Frequently Asked Questions
How does industrial die casting contribute to mechanical strength in connector housings?
Industrial die casting uses high-pressure injection of molten alloy into hardened steel tooling, producing a dense, void-free microstructure. This results in housings with higher tensile and shear strength compared to gravity-cast or machined alternatives, critical for connectors subject to torque, pull-out, and panel stress.
What is the expected service life of this connector assembly in continuous-duty applications?
Service life depends on mating cycles, current load, and environmental conditions. Die-cast assemblies with quality contact plating are designed for thousands of mating cycles and years of continuous electrical service. Proper installation and periodic inspection further extend operational life in demanding industrial settings.
Can this assembly handle both power and signal contacts within the same housing?
Yes. Precision die-cast housings can accommodate mixed-layout contact configurations combining power and signal contacts in a single assembly. This reduces wiring complexity and connector count in industrial control panels while maintaining electrical isolation between power and signal circuits.
Precision Connector Assembly 24 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
