Industrial / Precision Die Casting
Precision Connector Assembly 25
Industrial-grade precision connector assembly featuring a die-cast housing that provides dimensional stability and resistance to mechanical stress. Engineered to maintain reliable electrical contact in environments subject to vibration or thermal cycling. Frequently specified for robotics, motor drives, and heavy-duty electronic enclosures.
Key Features
- Die-cast housing provides superior dimensional stability under thermal and mechanical stress
- Resistant to deformation from panel mounting torque and cable pull forces
- Industrial-grade construction rated for harsh factory floor operating conditions
- Tight housing tolerances ensure consistent connector-to-connector mating alignment
- Compatible with standard industrial locking and latching hardware configurations
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 25 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial robot end-effector and tool changer electrical interfaces
CNC machine tool spindle drive and feedback wiring assemblies
Automated guided vehicle onboard power and communication connectors
Industrial IoT gateway and edge computing device field connections
High-cycle production line equipment requiring durable connector interfaces
Frequently Asked Questions
How does dimensional stability in the die-cast housing benefit long-term connector performance?
Dimensional stability prevents housing warpage or creep under sustained thermal and mechanical loads. This keeps contact cavities in precise alignment throughout the connector's service life, maintaining consistent insertion force, contact resistance, and mating reliability even after years of industrial operation.
What resistance does the die-cast housing offer against physical deformation during installation?
The metallic die-cast housing withstands panel cutout mounting torque, cable strain, and accidental impact without cracking or deforming. This is a significant advantage over thermoplastic housings in environments where connectors are frequently accessed by maintenance personnel or subject to physical stress.
Is this connector assembly compatible with standard industrial locking mechanisms?
Yes. The housing geometry is designed to interface with common industrial locking hardware including screw locks, bayonet rings, and push-pull latches. This ensures secure mating in vibration-prone environments and prevents accidental disconnection during machine operation.
Precision Connector Assembly 25 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
