Industrial / Precision Die Casting
Precision Connector Assembly 27
Connector assembly built with precision die casting techniques to achieve tight tolerances and consistent part geometry across high-volume production. Provides dependable mechanical and electrical performance in challenging operating conditions. Common applications include automated production lines, servo systems, and industrial sensor networks.
Key Features
- Precision die casting achieves tight tolerances and consistent part geometry throughout production
- Accurate contact cavity positioning minimizes misalignment during blind-mate connector operations
- High-repeatability manufacturing supports interchangeable replacement without field adjustment
- Dense alloy microstructure provides superior strength-to-weight ratio versus machined housings
- Suitable for high-precision instrumentation and measurement system interconnections
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 27 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Precision measurement instruments requiring repeatable connector interface geometry
Semiconductor fabrication equipment signal and power interconnection assemblies
Optical and photonic system alignment-sensitive connector interfaces
High-accuracy motion stage encoder and drive wiring assemblies
Laboratory automation equipment modular interconnection systems
Frequently Asked Questions
What tolerances are achievable with precision die casting for connector housings?
Precision die casting can achieve dimensional tolerances of ±0.05 to ±0.1 mm on critical features such as contact pitch, cavity diameter, and mating face flatness. These tolerances are sufficient for most industrial and instrumentation connector applications and can be tightened further with post-cast machining where required.
How does consistent part geometry benefit blind-mate connector applications?
In blind-mate applications where connectors are mated without visual guidance, consistent housing geometry ensures the mating halves align correctly every time. Tight tolerances on guide features and contact cavities prevent pin damage, reduce insertion force variation, and improve reliability in automated or rack-mount systems.
Are replacement units interchangeable without field calibration or adjustment?
Yes. The high dimensional repeatability of die-cast production means replacement connector assemblies are drop-in compatible with existing installations. This eliminates the need for field adjustment or shimming, reducing maintenance downtime and simplifying spare parts management in industrial and instrumentation applications.
Precision Connector Assembly 27 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
