Industrial / Precision Die Casting
Precision Connector Assembly 28
Precision connector assembly utilizing die-cast construction for enhanced rigidity and accurate connector alignment during mating cycles. Designed to withstand the mechanical demands of industrial installation and long-term operation. Applicable in control cabinets, power electronics, and field-installed industrial equipment.
Key Features
- Die-cast construction enhances housing rigidity for accurate connector alignment during mating
- Precision cavity geometry prevents contact skew and ensures full pin engagement
- Rigid shell resists flexure under cable weight and repeated mating cycle loads
- Enhanced rigidity supports reliable performance in high-vibration industrial environments
- Accurate alignment features reduce connector wear and extend mating cycle life
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 28 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Rack-mount server and network equipment high-density connector backplanes
Industrial press and stamping machine control wiring assemblies
Subsea and downhole instrumentation connector interface assemblies
Aerospace ground support equipment electrical interconnection systems
High-cycle automated test equipment device interface board connectors
Frequently Asked Questions
How does enhanced housing rigidity improve connector alignment during mating?
A rigid die-cast housing resists deflection under the forces applied during connector mating, keeping contact cavities in precise alignment throughout the insertion stroke. This prevents pin stubbing, reduces contact wear, and ensures full electrical engagement, which is critical in high-cycle or blind-mate applications.
What is the impact of housing rigidity on connector mating cycle life?
Rigid housings maintain consistent contact alignment across thousands of mating cycles, reducing the progressive wear caused by misalignment in flexible housings. This extends the rated mating cycle life of the connector assembly and reduces the frequency of replacement in high-cycle industrial and test equipment applications.
Is the connector assembly suitable for subsea or high-pressure environments?
With appropriate sealing and pressure-rated accessories, die-cast connector assemblies can be adapted for subsea or high-pressure downhole applications. The metallic housing provides the structural foundation for pressure-resistant sealing systems, though specific pressure ratings depend on the complete sealed assembly design.
Precision Connector Assembly 28 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
