Precision Connector Assembly 30
Industrial precision connector assembly with a die-cast housing engineered for structural consistency and reliable contact retention over extended service life. Precision tolerances support accurate alignment and repeatable mating performance. Designed for applications in factory automation, power management systems, and industrial electronics.
Key Features
- Die-cast housing engineered for structural consistency across high-volume production runs
- Reliable contact retention under thermal cycling and mechanical stress
- Precision mold tooling delivers repeatable part geometry batch after batch
- Industrial-grade construction withstands harsh factory floor conditions
- Stable interconnection performance validated for long-term deployment
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 30 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial control cabinet wiring and terminal block assemblies
Machine tool electrical interconnection and axis control wiring
Conveyor and material handling system power connections
Process automation sensor and actuator interface wiring
Energy management and power monitoring equipment assemblies
Frequently Asked Questions
What quality checks are applied to the die-cast housing?
Each housing undergoes dimensional inspection to verify mating surface geometry, wall thickness, and critical interface tolerances. Structural integrity checks confirm the casting is free from porosity, cracks, or surface defects that could compromise contact reliability or mechanical strength.
Can this connector assembly be customized for specific pin counts or configurations?
CZT supports OEM customization of die-cast connector assemblies including pin count, contact arrangement, housing dimensions, and surface finish. Contact our engineering team with your application requirements for a tailored solution.
What is the expected service life of this connector assembly?
The die-cast housing and precision contacts are designed for extended industrial service life. Actual longevity depends on mating cycles, operating environment, and load conditions. CZT can provide application-specific life expectancy data upon request.
Precision Connector Assembly 30 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
