Industrial / Precision Die Casting
Precision Connector Assembly 5
Die-cast precision connector assembly providing consistent dimensional accuracy and reliable interconnection performance for industrial applications. Robust construction supports secure mating and resistance to mechanical wear over time. Well suited for use in industrial machinery, motion control systems, and electronic assemblies.
Key Features
- Consistent dimensional accuracy ensured by precision die-cast tooling and process control
- Reliable interconnection performance across repeated mating and unmating cycles
- Robust die-cast housing maintains structural integrity under mechanical stress
- Tight contact-to-housing tolerances reduce signal path resistance variation
- Suitable for integration into multi-connector industrial wiring harness assemblies
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 5 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial robot arm joint wiring and signal routing
CNC machine tool spindle and axis control connections
Packaging and labeling machinery electrical assemblies
Hydraulic and pneumatic control system interface wiring
Rail and transit vehicle onboard electrical systems
Frequently Asked Questions
What dimensional tolerances can be achieved with die-cast connector housings?
High-pressure die casting typically achieves tolerances of ±0.1 mm or better on critical mating dimensions, depending on part geometry and alloy selection. CZT's tooling and process controls are optimized to maintain consistent tolerances across production batches.
Can this assembly be used in outdoor or moisture-exposed environments?
The die-cast housing provides inherent resistance to moisture ingress compared to open-frame designs. For outdoor or wash-down applications, CZT recommends specifying additional sealing options such as gaskets or overmolded strain relief to achieve the required IP protection rating.
What contact materials are used in the connector assembly?
Contacts are manufactured from copper alloy with plating options including tin, nickel, or gold depending on the application's current rating, mating cycle requirements, and environmental conditions. Gold plating is recommended for low-level signal applications requiring minimal contact resistance.
Precision Connector Assembly 5 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
