Industrial / Precision Die Casting
Precision Connector Assembly 6
Precision connector assembly featuring die-cast construction that ensures tight part tolerances and stable electrical contact in industrial environments. Designed to perform reliably under conditions involving vibration, temperature variation, and repeated connection cycles. Applicable in automation systems, power electronics, and industrial control infrastructure.
Key Features
- Tight part tolerances achieved through controlled high-pressure die casting process
- Stable electrical contact maintained under vibration, shock, and thermal variation
- Die-cast construction provides superior EMI shielding compared to plastic housings
- Precision mating surfaces reduce connector wear over high-cycle applications
- Compatible with standard industrial connector mounting and panel cutout dimensions
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 6 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial Ethernet and fieldbus network infrastructure wiring
Power electronics and inverter system interface connections
Semiconductor fabrication equipment electrical assemblies
Medical device manufacturing line control wiring
Aerospace ground support equipment electrical interconnections
Frequently Asked Questions
Does the die-cast housing provide EMI/RFI shielding?
Yes. Die-cast metal housings provide effective electromagnetic shielding, reducing radiated emissions and improving immunity to external interference. This is particularly valuable in industrial environments with variable-frequency drives, switching power supplies, and other high-frequency noise sources.
What is the operating temperature range for this connector assembly?
Die-cast alloy housings maintain dimensional stability across a wide temperature range, typically -40°C to +125°C depending on alloy and contact material selection. Specific thermal ratings are confirmed during application engineering review.
How are contact positions secured within the die-cast housing?
Contacts are retained using precision-formed locking features integrated into the housing cavity design. This ensures contacts remain positively seated under mating forces, vibration, and cable pull loads without requiring secondary retention hardware.
Precision Connector Assembly 6 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
