Precision Connector Assembly 8
Precision connector assembly with a die-cast housing designed for dimensional consistency and long-term reliability in industrial interconnection applications. The manufacturing process ensures repeatable part quality suitable for high-volume industrial deployments. Common applications include factory automation, energy management equipment, and industrial communication systems.
Key Features
- Die-cast housing designed for dimensional consistency and long-term field reliability
- Precision contact geometry maintains low insertion force across mating cycles
- Robust housing wall thickness resists deformation under panel mounting torque
- Alloy construction provides stable performance across wide temperature extremes
- Engineered for compatibility with standard industrial wiring harness termination methods
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: Custom connector or industrial hardware
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Precision Connector Assembly 8 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyCustom connector or industrial hardware
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Industrial motor control center (MCC) wiring and bus connections
Automated guided vehicle (AGV) onboard electrical systems
Food and beverage processing equipment control wiring
Water treatment plant instrumentation and control assemblies
Elevator and escalator drive system electrical connections
Frequently Asked Questions
How does CZT ensure long-term reliability of die-cast connector assemblies?
Reliability is built in through precision tooling maintenance, alloy composition control, and 100% dimensional inspection of critical mating features. Assemblies undergo electrical continuity and contact retention testing before shipment to verify performance meets specification.
Are replacement contacts available for field repair of these assemblies?
CZT can supply individual contact components and housing parts to support field maintenance programs. Customers operating large installed bases of CZT connectors are encouraged to establish spare parts agreements to minimize equipment downtime.
What wire gauge range is compatible with this connector assembly?
Contact termination is designed to accommodate a specific wire gauge range determined by the contact cavity size and crimp tooling specification. CZT provides full termination tooling recommendations and wire gauge compatibility data with each connector assembly product.
Precision Connector Assembly 8 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
