两叉金片 Gold Contact Series
Model:两叉金片
Two-prong gold contact stamping with a high-quality electroplated finish, inspected to ensure no white streaks, reddening, blackening, haze, burn marks, or surface contamination. Color consistency is maintained within the same reel and across batches, with no variation in plating luster permitted. Designed for use in precision electrical connectors, relay contacts, and electronic assemblies where consistent contact resistance and surface quality are essential.
Key Features
- Two-prong stamped gold contact with electroplated finish meeting strict appearance criteria
- No white streaks, reddening, blackening, haze, burn marks, or contamination permitted
- Batch color consistency controlled — no color variation within same production reel
- 90° bend test with pliers confirms plating adhesion with no peeling or delamination
- Precision stamping geometry ensures consistent two-prong contact alignment
Key Specifications
- Service type: connector terminal electroplating / selective plating
- Connector family: Custom connector or industrial hardware
- Plating focus: gold, nickel, tin, or selective plating stack per customer drawing and RFQ requirements
- Quality focus: appearance, adhesion, bending performance, contact zone consistency, and batch color control where applicable
- +11 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Gold Contact Series Specifications
Service typeconnector terminal electroplating / selective plating
Connector familyCustom connector or industrial hardware
Plating focusgold, nickel, tin, or selective plating stack per customer drawing and RFQ requirements
Quality focusappearance, adhesion, bending performance, contact zone consistency, and batch color control where applicable
Drawing statusRequest Drawing or plating specification during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm substrate material, plating stack, thickness, contact area, reel / barrel / rack process, masking requirements, test method, and inspection criteria
1. AppearanceA、no white streaks、reddening、blackening、haze、burn marks、contamination；
B、色差same reel, no color difference in same batch；
C、色泽no plating luster；
2. Bonding Strengthtake a gold strip and bend with pliers90° check bending for peeling
3. Salt Spray Test (5% NaCl Solution)3-6μ＂:24H；15-60μ＂:48H；no verdigris on gold strip after test、reddening oxidation
Storage Temperature35°Cor below；
Storage Humidity55%within；
SpecificationCD636；
Typical Applications
PCB-mounted two-prong contact terminals in consumer electronics
Battery contact assemblies in portable and handheld devices
Spring-loaded two-point contacts in SIM card and memory card sockets
Low-voltage signal contacts in industrial sensor connectors
Two-prong pogo pin replacements in test fixture and docking applications
Frequently Asked Questions
How is plating adhesion tested on the two-prong gold contact?
A gold strip sample is bent 90° using pliers and the bent area is inspected for peeling or delamination of the gold layer from the base metal. This mechanical stress test simulates the forces applied during connector assembly and confirms that the plating bond is sufficient to survive handling and installation.
What causes white streaks or reddening in gold-plated contacts, and how are they prevented?
White streaks typically indicate plating bath contamination or insufficient rinsing, while reddening suggests copper base metal exposure from thin or porous gold deposits. CZT controls bath chemistry, plating current density, and post-plate rinsing protocols, with 100% visual inspection to reject any parts showing these defects before shipment.
Can the two-prong contact geometry be customized for specific connector housings?
Yes. Stamping tooling can be modified to adjust prong spacing, width, thickness, and overall contact length to match specific housing cavities or PCB footprints. Custom designs are validated against the same appearance, color consistency, and bend adhesion standards applied to standard production parts.
Gold Contact Series Details
CategoryIndustrial
SubcategoryElectroplating
Model Number两叉金片
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
