10730111F001 SFP28+ 1X1 Connector with CZT 30U
Model:10730111F001
The SFP28+ 1X1 Connector with CZT 30U (10730111F001) is engineered for 25G small form-factor pluggable transceiver modules, with 30 microinch gold plating on contacts for extended mating life and signal reliability. Its compact single-port cage design integrates cleanly into high-density line cards and switch fabrics. Used in 25G Ethernet, storage networking, and next-generation telecom access equipment.
Key Features
- Engineered for 25G SFP28 small form-factor pluggable transceivers
- 30U gold plating on contacts for extended insertion cycle durability
- 1×1 single-port configuration for high-density line card designs
- High-frequency contact geometry optimized for 25 Gbps signal integrity
- Compliant with SFF-8432 and SFP28 MSA mechanical specifications
Key Specifications
- Product family: SFP28 optical connector
- Port / layout: 1x1 / single-port
- Pin / contact count: confirm from drawing
- Mounting / option notes: confirm mounting and options from drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP28+ 1X1 Connector with CZT 30U Specifications
Product familySFP28 optical connector
Port / layout1x1 / single-port
Pin / contact countconfirm from drawing
Mounting / option notesconfirm mounting and options from drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusold-site product image available
RFQ checkconfirm drawing revision, mating connector, PCB thickness or panel cutout, plating thickness, LED / light-pipe option, shielding, packaging, and sample requirement
Typical Applications
25G data center top-of-rack switch line cards
High-speed server NIC and SmartNIC designs
Optical transceiver cage assemblies for 25GbE links
Telecom equipment requiring SFP28 hot-plug interfaces
Storage area network switches with 25G uplink ports
Frequently Asked Questions
Why is 30U gold plating specified for the SFP28 connector?
SFP28 transceivers are frequently hot-swapped during maintenance and upgrades, subjecting contacts to repeated insertion cycles. 30 microinch gold plating provides significantly greater wear resistance than standard 15U plating, maintaining low contact resistance and reliable signal integrity over the connector's service life.
Is the 10730111F001 compliant with SFP28 MSA specifications?
The connector is engineered to meet SFP28 MSA mechanical and electrical requirements. Buyers should request CZT's compliance documentation and test reports to confirm conformance with SFF-8432 dimensional specs and the electrical performance requirements of their specific 25G application.
Can this connector support SFP+ (10G) transceivers as well as SFP28 (25G)?
SFP28 connectors are mechanically backward compatible with SFP+ modules. The 10730111F001 can physically accept SFP+ transceivers, but the host system's PHY and firmware must negotiate the appropriate data rate. Electrical performance at 10G will be well within the connector's rated capability.
SFP28+ 1X1 Connector with CZT 30U Details
CategoryNew Products
Model Number10730111F001
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
