10735111F001 QSFP28+1X1 Connector 30U A TYPE with CZT
Model:10735111F001
The QSFP28+ 1X1 Connector 30U A Type (10735111F001) supports 100G data transmission and features 30 microinch gold plating for enhanced contact durability and corrosion resistance. Designed to meet the mechanical and electrical demands of high-speed transceiver modules, it is widely used in data center networking, high-performance computing, and enterprise switching platforms.
Key Features
- QSFP28+ 1X1 cage supporting 100G data transmission rates
- 30 microinch gold plating on contacts for low-resistance, long-cycle performance
- Type A configuration compliant with QSFP28 MSA mechanical specification
- High-density single-port design optimized for line card integration
- Engineered for high-speed differential pair signal integrity at 25Gbps per lane
Key Specifications
- Product family: QSFP28 optical connector
- Port / layout: 1x1 / single-port
- Pin / contact count: confirm from drawing
- Mounting / option notes: confirm mounting and options from drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
QSFP28+1X1 Connector 30U A TYPE with CZT Specifications
Product familyQSFP28 optical connector
Port / layout1x1 / single-port
Pin / contact countconfirm from drawing
Mounting / option notesconfirm mounting and options from drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusold-site product image available
RFQ checkconfirm drawing revision, mating connector, PCB thickness or panel cutout, plating thickness, LED / light-pipe option, shielding, packaging, and sample requirement
Typical Applications
100G Ethernet switch and router line card optical port hosting
Data center spine and leaf switch high-density port arrays
100G coherent optical transceiver module integration
High-performance computing cluster interconnect interfaces
Telecom access and aggregation equipment 100G uplink ports
Frequently Asked Questions
What does 30 microinch gold plating provide over standard plating thicknesses?
30 microinch (30µin) gold plating offers a thicker, more durable contact surface compared to standard 15µin flash gold. This reduces contact resistance degradation over repeated insertion cycles, minimizes oxidation in humid environments, and is particularly important for high-speed differential signals where contact impedance consistency is critical.
Is the QSFP28+ 1X1 connector compatible with QSFP+ 40G modules?
The QSFP28+ cage is mechanically compatible with QSFP+ modules as both share the same physical form factor per the MSA specification. However, electrical performance at 100G (4x25G) requires the full QSFP28+ signal path. Using a QSFP+ 40G module in the cage will function at 40G rates.
What PCB design considerations apply for the QSFP28+ 1X1 connector?
At 25Gbps per lane, PCB trace impedance control, via stub minimization, and differential pair length matching are critical. CZT provides a recommended PCB footprint and signal routing guidelines with the connector datasheet. Consult your signal integrity team to validate the channel simulation before finalizing layout.
QSFP28+1X1 Connector 30U A TYPE with CZT Details
CategoryNew Products
Model Number10735111F001
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
