A产品 Hard Gold Series
Model:A产品
Hard Gold Series electroplated connector (Model A) from CZT delivers a flawless surface finish with strict quality controls against yellow spots, black spots, water stains, and plating skip defects. Each unit is inspected for scratches, abrasion, deformation, and pin misalignment to ensure dimensional and cosmetic integrity. Suited for high-reliability applications in telecommunications, aerospace, and industrial control systems where consistent contact performance is critical.
Key Features
- Hard gold electroplating with zero tolerance for surface defects
- Inspected for yellow spots, black spots, water stains, and plating skip
- Bonding strength verified by needle-nose pliers bend test without peeling
- No pin misalignment, deformation, or product overlap accepted at QC
- Consistent plating thickness for reliable contact resistance in service
Key Specifications
- Service type: connector terminal electroplating / selective plating
- Connector family: Custom connector or industrial hardware
- Plating focus: gold, nickel, tin, or selective plating stack per customer drawing and RFQ requirements
- Quality focus: appearance, adhesion, bending performance, contact zone consistency, and batch color control where applicable
- +11 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Hard Gold Series Specifications
Service typeconnector terminal electroplating / selective plating
Connector familyCustom connector or industrial hardware
Plating focusgold, nickel, tin, or selective plating stack per customer drawing and RFQ requirements
Quality focusappearance, adhesion, bending performance, contact zone consistency, and batch color control where applicable
Drawing statusRequest Drawing or plating specification during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm substrate material, plating stack, thickness, contact area, reel / barrel / rack process, masking requirements, test method, and inspection criteria
1. AppearanceA、no yellow spots、black spots、white spots、water stains、incomplete degreasing、plating skip etc.；
B、no plating scratches、abrasion；
C、no product overlap、deformation、pin misalignment etc.；
2. Bonding Strengthbend with needle-nose pliers, no plating peeling；
3. IR Reflowproduct afterIRoven test(265 °C±5)no deformation after、blistering、discoloration anomalies。(this item only applies to products withIRtest requirement products)；
4. Solderabilityproduct after steam aging test(temp.:97 °C time:8H)after, select tin-plated area for soldering test(dip in flux then immerse in
锡炉3-5s, temp.245±5 °C), using10--30x magnification, allow continuousPinhole、non-wetting and solder shrinkage defects,
solder coverage of total tested area95%；
Typical Applications
High-reliability PCB edge connectors requiring hard gold contacts
Aerospace and defense connector contacts with strict surface standards
Medical device connectors demanding defect-free plating integrity
High-cycle mating connectors where gold wear resistance is critical
Precision instrumentation connectors with low contact resistance requirements
Frequently Asked Questions
What is the advantage of hard gold plating over standard gold flash?
Hard gold (typically gold-cobalt or gold-nickel alloy) offers significantly higher wear resistance than soft or flash gold. It maintains stable contact resistance over thousands of mating cycles, making it the preferred choice for edge card connectors, test sockets, and high-reliability interconnects in demanding environments.
How does CZT inspect for plating defects on Model A connectors?
Each batch undergoes visual inspection for surface anomalies including yellow spots, black spots, white spots, water stains, incomplete degreasing, and plating skip. Mechanical bonding strength is validated by bending with needle-nose pliers — any plating that peels is rejected. No scratches or abrasion marks are accepted.
What plating thickness options are available for the Hard Gold Series?
CZT can accommodate various gold thickness specifications depending on application requirements. Contact the technical team with your mating cycle count, operating environment, and contact resistance targets to determine the appropriate gold thickness — typically ranging from 0.1 µm flash to 1.27 µm or more for high-wear applications.
Hard Gold Series Details
CategoryIndustrial
SubcategoryElectroplating
Model NumberA产品
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
