QSFP Structural Part 5
Precision die-cast QSFP structural component engineered to meet the mechanical demands of high-speed transceiver assemblies. This part delivers consistent dimensional accuracy and surface finish, supporting secure module mating and long-term structural integrity. Suitable for integration into network switches, routers, and active optical cable assemblies operating in data center environments.
Key Features
- High-pressure die-cast QSFP component engineered for high-speed transceiver mechanical demands
- Optimized geometry ensures precise PCB and optical sub-assembly alignment
- Thermal dissipation features support module power budgets up to 3.5W
- Consistent part-to-part repeatability enables high-throughput automated assembly
- Alloy selection provides corrosion resistance in humid and industrial environments
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: QSFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
QSFP Structural Part 5 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyQSFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
QSFP28 100G CWDM4 and PSM4 optical module assemblies
Data center fabric switch high-density optical port modules
5G fronthaul and midhaul optical transceiver manufacturing
Industrial Ethernet QSFP module ruggedized housing production
Cloud provider custom optical transceiver OEM programs
Frequently Asked Questions
How does CZT ensure dimensional repeatability across large production batches?
CZT uses hardened steel tooling with controlled shot parameters including injection pressure, temperature, and cooling time. Statistical process control (SPC) is applied to critical dimensions, and CMM inspection is performed on a sampling basis per batch to verify conformance to drawing tolerances.
What is the thermal conductivity of the die-cast alloy used in QSFP Structural Part 5?
Zinc alloys used in this application typically exhibit thermal conductivity of 100–115 W/m·K, while aluminum alloys offer 140–160 W/m·K. The specific alloy is selected based on the module's thermal budget and mechanical requirements, and can be specified by the customer.
Does this part require secondary machining after die casting?
Most critical features are net-shape from the die casting process, minimizing secondary operations. However, CZT can provide post-cast CNC machining for features requiring tighter tolerances than die casting alone can achieve, such as precision bore diameters or threaded inserts.
QSFP Structural Part 5 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
