QSFP Structural Part 7
Die-cast QSFP structural component designed to serve as a key mechanical element within high-speed optical transceiver modules. Precision casting ensures accurate fitment, reliable latch engagement, and effective heat transfer across the module assembly. Typical applications include enterprise and carrier-grade networking equipment, optical interconnect systems, and high-performance computing infrastructure.
Key Features
- Die-cast QSFP structural element serving as primary mechanical housing for optical transceivers
- Engineered for structural integrity under IEC 61300-2-4 mechanical shock and vibration
- Precision mating surfaces ensure reliable optical alignment within transceiver assembly
- Alloy housing provides continuous EMI shielding for high-speed electrical interfaces
- Scalable production tooling supports both prototype and mass volume supply requirements
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: QSFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
QSFP Structural Part 7 Specifications
Product typeprecision die-cast structural component
Connector / hardware familyQSFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
High-speed QSFP optical transceiver module mechanical assembly
400G QSFP-DD module predecessor component manufacturing
Data center and HPC optical interconnect transceiver production
Ruggedized QSFP module housing for industrial network equipment
OEM optical module brands requiring precision die-cast housing supply
Frequently Asked Questions
What role does QSFP Structural Part 7 play in the overall transceiver assembly?
This component serves as a primary mechanical element of the QSFP module, providing the structural frame that houses the PCB, optical engine, and electrical interface. It ensures dimensional compliance with the QSFP MSA cage interface and protects internal components from mechanical and electromagnetic stress.
Can this part be used in QSFP-DD module designs as well?
QSFP Structural Part 7 is dimensioned for standard QSFP form factor assemblies. QSFP-DD has a different mechanical envelope per its MSA specification. CZT can develop custom tooling for QSFP-DD structural parts if required — contact our engineering team to discuss your design requirements.
What certifications or material documentation can CZT provide with this part?
CZT can supply material certificates (alloy composition and mechanical properties), RoHS compliance declarations, dimensional inspection reports, and PPAP documentation upon request. Custom quality documentation packages can be arranged to support customer qualification and incoming inspection processes.
QSFP Structural Part 7 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
