SRQ-XJ-26
The SRQ-XJ-26 heat sink is designed to mount directly to power modules and discrete semiconductors in industrial enclosures. CZT's manufacturing process ensures flat base surface contact for minimal thermal interface resistance. Used in solar inverters, electric vehicle charging equipment, and high-current switching circuits.
Key Features
- Direct-mount design for power modules and discrete semiconductors in industrial enclosures
- Flat precision base ensures intimate thermal contact with module mounting surfaces
- Fin array geometry optimized for enclosure-internal airflow patterns
- Mounting provisions compatible with standard power module bolt patterns
- Durable anodized finish resists corrosion in industrial cabinet environments
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-XJ-26 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Direct mounting to IGBT and diode modules in industrial drives
Power module cooling in enclosed industrial control cabinets
Heat dissipation for discrete semiconductors in panel-mount assemblies
Thermal management in industrial frequency converter enclosures
Cooling for power devices in enclosed motor control centers
Frequently Asked Questions
What is the advantage of a direct-mount heat sink design like the SRQ-XJ-26?
Direct mounting eliminates intermediate thermal interfaces between the power module and heat sink, reducing the total thermal resistance path. This allows higher power dissipation within a given temperature budget or enables a smaller heat sink for the same power level compared to indirect mounting arrangements.
How does the SRQ-XJ-26 perform in low-airflow industrial enclosures?
The SRQ-XJ-26 fin geometry is designed to function effectively in the restricted airflow conditions typical of closed industrial enclosures. For very low airflow environments, natural convection performance data should be used for thermal sizing. Adding internal circulation fans significantly improves performance in sealed cabinets.
Are custom bolt patterns available for non-standard power module footprints?
Yes. CZT offers custom drilling and tapping services for OEM orders requiring non-standard module mounting patterns. Provide your module's mechanical drawing and mounting specifications, and CZT's engineering team will confirm feasibility and lead time for customized SRQ-XJ-26 units.
SRQ-XJ-26 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
