SRQ-XJ-30
The SRQ-XJ-30 heat sink is built for industrial applications requiring durable, low-maintenance thermal management solutions. Its aluminum alloy body offers a favorable strength-to-weight ratio alongside good thermal conductivity. Suitable for power rectifiers, onboard chargers, and distributed control system hardware.
Key Features
- Ruggedized construction designed for long-service industrial environments
- Low-maintenance passive design with no moving parts or consumables
- High-purity aluminum alloy base for superior thermal conductivity
- Resistant to vibration and mechanical shock in industrial installations
- Standardized footprint simplifies drop-in replacement and system integration
Key Specifications
- Product type: heat sink / thermal management component
- Application focus: optical transceiver, networking, power electronics, or industrial electronics thermal management
- Material: aluminum alloy reference; confirm final alloy, temper, and finish during RFQ
- Process note: confirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SRQ-XJ-30 Specifications
Product typeheat sink / thermal management component
Application focusoptical transceiver, networking, power electronics, or industrial electronics thermal management
Materialaluminum alloy reference; confirm final alloy, temper, and finish during RFQ
Process noteconfirm extrusion, die casting, CNC machining, skiving, bonding, or surface finishing from the customer drawing
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm dimensions, fin geometry, thermal interface, mounting method, surface finish, packaging, and drawing revision
Typical Applications
Thermal management in industrial control panels and PLCs
Cooling power modules in heavy machinery drive systems
Heat dissipation for solid-state relays in automation equipment
Long-life thermal solutions for remote monitoring hardware
Industrial power supplies in harsh factory floor environments
Frequently Asked Questions
How does the SRQ-XJ-30 handle vibration in industrial machinery applications?
The SRQ-XJ-30 is manufactured from a single extruded aluminum profile, eliminating joints or bonded fins that could loosen under vibration. When properly fastened using the provided mounting points, it maintains reliable thermal contact with the device under typical industrial vibration profiles.
What is the expected service life of the SRQ-XJ-30 in continuous operation?
As a fully passive component with no moving parts, the SRQ-XJ-30 has an indefinite mechanical service life under normal operating conditions. Thermal performance remains stable as long as the mounting interface is maintained and the fin channels are kept free of dust accumulation.
Is the SRQ-XJ-30 suitable for outdoor or protected outdoor enclosures?
The SRQ-XJ-30 is designed for indoor and protected outdoor use. Its anodized finish provides adequate corrosion resistance for IP54-class enclosures. For fully exposed outdoor deployments, additional protective coatings or sealed enclosure mounting is recommended.
SRQ-XJ-30 Details
CategoryIndustrial
SubcategoryHeat Sinks
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
