There are over 15 different electrical plug types used around the world — a legacy of independent national electrical standards developed over the past century. For travelers, equipment manufacturers, and anyone importing or exporting electrical products, understanding plug types is essential.
This guide covers the major plug types, their specifications, and where they're used.
Why So Many Plug Types?
Electrical standards developed independently in different countries during the early 20th century. By the time international standardization was attempted, too much infrastructure was already in place to change. The result: 15+ plug types, two main voltage standards (120V and 230V), and two frequency standards (50 Hz and 60 Hz).
The IEC (International Electrotechnical Commission) has been working toward standardization with the IEC 60083 standard and the IEC 60906-1 (Type N) universal plug, but adoption has been slow.
Major Plug Types
Type A — Two Flat Parallel Blades
- Voltage: 120 V
- Frequency: 60 Hz
- Current: 15 A
- Grounding: No (ungrounded)
- Countries: USA, Canada, Mexico, Japan, Central America
- Notes: The most common plug in North America. Polarized (one blade wider than the other). No earth pin.
Type B — Two Flat Blades + Round Earth Pin
- Voltage: 120 V
- Frequency: 60 Hz
- Current: 15 A
- Grounding: Yes (round earth pin)
- Countries: USA, Canada, Mexico
- Notes: Grounded version of Type A. The earth pin is longer, ensuring ground connection before live pins. Type A plugs fit Type B sockets.
Type C — Two Round Pins (Europlug)
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 2.5 A
- Grounding: No
- Countries: Most of Europe, South America, Asia, Africa
- Notes: The most widely used plug type globally. Ungrounded — only suitable for double-insulated appliances. Fits into Type E, F, and other European sockets.
Type D — Three Round Pins (Large)
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 5 A
- Grounding: Yes
- Countries: India (older installations), some African countries
- Notes: Large triangular pin arrangement. Being replaced by Type M in India.
Type E — Two Round Pins + Round Earth Hole
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 16 A
- Grounding: Yes (earth pin in socket, not plug)
- Countries: France, Belgium, Poland, Czech Republic, Slovakia
- Notes: The earth connection is a pin in the socket that inserts into a hole in the plug. Type C plugs fit Type E sockets.
Type F — Two Round Pins + Earth Clips (Schuko)
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 16 A
- Grounding: Yes (earth clips on sides)
- Countries: Germany, Austria, Netherlands, most of Europe, Russia
- Notes: "Schuko" (Schutzkontakt = protective contact). Earth connection via metal clips on the sides of the socket. Type C plugs fit Type F sockets. Most common European standard.
Type G — Three Rectangular Blades
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 13 A
- Grounding: Yes
- Countries: UK, Ireland, Hong Kong, Singapore, Malaysia, Australia (some)
- Notes: Has a fuse inside the plug (3 A or 13 A). The earth pin is longer and opens shutters protecting the live and neutral holes. One of the safest plug designs.
Type H — Three Pins (V-Shape)
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 16 A
- Grounding: Yes
- Countries: Israel only
- Notes: Unique V-shaped pin arrangement. Israel is transitioning to Type C compatibility.
Type I — Two or Three Flat Angled Blades
- Voltage: 230 V (AU/NZ), 120 V (China variant)
- Frequency: 50 Hz
- Current: 10 A (AU/NZ), 16 A (AU/NZ large)
- Grounding: Yes (3-pin) or No (2-pin)
- Countries: Australia, New Zealand, China, Argentina
- Notes: The Australian/NZ version has angled flat blades in a V arrangement. The Chinese version (GB 2099) looks similar but is not intermateable. Argentina uses a variant with round pins.
Type J — Three Round Pins
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 10 A
- Grounding: Yes
- Countries: Switzerland, Liechtenstein
- Notes: Unique to Switzerland. Type C plugs fit Type J sockets.
Type K — Two Round Pins + U-Shaped Earth
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 16 A
- Grounding: Yes
- Countries: Denmark, Greenland
- Notes: Unique to Denmark. Type C plugs fit Type K sockets.
Type L — Three Round Pins (In-Line)
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 10 A or 16 A
- Grounding: Yes
- Countries: Italy, Chile, Uruguay
- Notes: Three pins in a line. Two sizes (10 A and 16 A) are not intermateable.
Type M — Three Large Round Pins
- Voltage: 230 V
- Frequency: 50 Hz
- Current: 15 A
- Grounding: Yes
- Countries: South Africa, India (new standard), Swaziland
- Notes: Similar to Type D but larger. South Africa's standard plug.
Type N — Two Round Pins + Round Earth (IEC Standard)
- Voltage: 127 V or 230 V
- Frequency: 50/60 Hz
- Current: 10 A or 20 A
- Grounding: Yes
- Countries: Brazil (mandatory since 2010), some other countries adopting
- Notes: IEC 60906-1 standard — designed as a universal replacement. Brazil has fully adopted it.
Voltage and Frequency by Region
| Region | Voltage | Frequency |
|---|---|---|
| North America | 120 V | 60 Hz |
| Europe | 230 V | 50 Hz |
| Australia / NZ | 230 V | 50 Hz |
| Japan | 100 V | 50/60 Hz |
| China | 220 V | 50 Hz |
| India | 230 V | 50 Hz |
| Brazil | 127 V or 220 V | 60 Hz |
Important: Voltage matters more than plug type. A 120V appliance plugged into a 230V outlet (with an adapter) will be destroyed. Always check the appliance's input voltage range before using an adapter.
Most modern electronics (laptops, phone chargers, camera chargers) are universal voltage (100–240 V, 50/60 Hz) — they work anywhere with just a plug adapter.
Travel Adapters vs Voltage Converters
- Plug adapter: Changes the plug shape only — does NOT convert voltage
- Voltage converter: Changes the voltage (120V ↔ 230V) — needed for single-voltage appliances
- Universal power supply: Built into most modern electronics — no converter needed
Check the appliance label: "Input: 100–240V, 50/60Hz" = universal, needs adapter only. "Input: 120V, 60Hz" = single voltage, needs converter for 230V countries.
Summary
There are 15+ electrical plug types worldwide, with Type A/B (North America), Type C/F (Europe), Type G (UK/AU), and Type I (Australia) being the most common.
Key points:
- Type C (Europlug) is the most widely compatible — fits most European sockets
- Type G (UK) is one of the safest designs — fused plug, shuttered socket
- Voltage matters: A plug adapter doesn't convert voltage — check appliance compatibility
- Most modern electronics are universal voltage — only a plug adapter is needed
- Brazil has adopted Type N (IEC standard) — the closest thing to a universal plug
