592*4大插芯扁针 Flat Pin Series
Model:592*4大插芯扁针
The 592×4 Large Insert Flat Pin is a larger-core variant of the 592×4 series, providing increased contact surface area for applications requiring higher current capacity or more robust mechanical retention. The flat-pin design ensures stable insertion and withdrawal cycles within compatible housings. Suited for power distribution connectors, industrial equipment terminals, and heavy-duty lighting assemblies.
Key Features
- Larger-core 592×4 series contact with increased contact surface area
- Higher current capacity compared to small insert variant in same housing family
- Gold plating provides low contact resistance for power circuit applications
- Compatible with 592×4 connector housings for mixed-contact system designs
- Robust contact geometry supports reliable mating under higher load conditions
Key Specifications
- Service type: connector terminal electroplating / selective plating
- Connector family: Custom connector or industrial hardware
- Plating focus: gold, nickel, tin, or selective plating stack per customer drawing and RFQ requirements
- Quality focus: appearance, adhesion, bending performance, contact zone consistency, and batch color control where applicable
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
Flat Pin Series Specifications
Service typeconnector terminal electroplating / selective plating
Connector familyCustom connector or industrial hardware
Plating focusgold, nickel, tin, or selective plating stack per customer drawing and RFQ requirements
Quality focusappearance, adhesion, bending performance, contact zone consistency, and batch color control where applicable
Drawing statusRequest Drawing or plating specification during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm substrate material, plating stack, thickness, contact area, reel / barrel / rack process, masking requirements, test method, and inspection criteria
Typical Applications
Power circuit contacts in 592×4 series connector assemblies
Mixed power and signal connectors using large and small insert contacts
Industrial equipment power distribution connector contacts
Higher current LED driver connector power pins
Automotive accessory power connector contacts
Frequently Asked Questions
What current rating advantage does the 592×4 Large Insert offer over the Small Insert?
The Large Insert's increased contact surface area reduces current density at the mating interface, allowing it to handle higher continuous current without excessive temperature rise. This makes it the preferred choice for power circuits within a 592×4 connector assembly, while small inserts handle signal lines.
Can Large Insert and Small Insert contacts be used in the same 592×4 housing?
Yes. The 592×4 series is designed to accommodate both insert sizes within the same housing family, enabling hybrid connector configurations that assign large inserts to power positions and small inserts to signal positions. This is a common design approach in mixed power/signal connector assemblies.
What plating finish is available for the 592×4 Large Insert Flat Pin?
The 592×4 Large Insert is available with gold plating, which provides low contact resistance and corrosion resistance suitable for both power and signal applications. Contact CZT to confirm available plating thickness options and whether tin-plated variants are offered for your specific application.
Flat Pin Series Details
CategoryIndustrial
SubcategoryElectroplating
Model Number592*4大插芯扁针
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
