Industrial / Precision Die Casting
SFP+Structural Part
SFP+ structural part manufactured using precision die casting to deliver consistent mechanical performance in small form-factor pluggable transceiver assemblies. The component provides structural support, EMI shielding, and dimensional accuracy required for reliable SFP+ module operation. Commonly used in 10G optical transceivers, enterprise switches, and fiber-optic communication systems.
Key Features
- Precision die-cast construction ensures tight dimensional tolerances for SFP+ housings
- High mechanical strength supports repeated plug/unplug mating cycles
- Consistent wall thickness and surface finish across production batches
- Designed to meet SFP+ MSA mechanical envelope requirements
- Suitable for EMI shielding integration within transceiver assemblies
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ optical transceiver module housing assembly
10G Ethernet switch port cage structural components
Active copper cable SFP+ connector mechanical housing
Telecom equipment small form-factor pluggable module frames
Industrial fiber optic transceiver structural enclosures
Frequently Asked Questions
What alloy is used in the precision die casting of SFP+ structural parts?
CZT typically uses zinc alloy (Zamak) or aluminum alloy depending on the weight, strength, and EMI shielding requirements of the specific SFP+ design. Zinc alloys offer superior dimensional accuracy for fine-feature parts, while aluminum provides a better strength-to-weight ratio for larger housings.
How does precision die casting compare to stamping for SFP+ structural parts?
Die casting enables complex three-dimensional geometries, undercuts, and integrated features that stamping cannot achieve in a single step. For SFP+ housings requiring precise internal cavities, latch features, and EMI fingers, die casting delivers better dimensional consistency and reduces secondary machining operations.
What dimensional tolerances can be held on die-cast SFP+ parts?
CZT's precision die casting process typically holds tolerances of ±0.05mm on critical mating dimensions, ensuring compatibility with SFP+ MSA cage and PCB footprint specifications. Critical features such as latch slots and guide rails are held to tighter tolerances as required by customer drawings.
SFP+Structural Part Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
