Industrial / Precision Die Casting
SFP+Structural Part 1
Precision die-cast SFP+ structural component engineered for use in small form-factor pluggable transceiver housings requiring tight tolerances and durable construction. The part supports proper module alignment, secure retention, and effective electromagnetic shielding in high-speed data links. Applicable in 10G SFP+ transceivers deployed across telecom, data center, and industrial networking environments.
Key Features
- Engineered for SFP+ transceiver housings with strict dimensional compliance
- Precision die casting delivers repeatable mechanical performance at volume
- Robust latch and guide rail features for secure cage mating
- Surface finish optimized for post-process plating or coating adhesion
- Designed to withstand thermal cycling in active transceiver environments
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 1 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
SFP+ transceiver module structural frame manufacturing
High-density 10G/25G switch port module assemblies
Fiber channel HBA transceiver housing components
Data center interconnect active optical module frames
Carrier-grade telecom SFP+ module mechanical structures
Frequently Asked Questions
Is this SFP+ structural part compatible with standard MSA cage dimensions?
Yes. SFP+ structural parts from CZT are designed to conform to SFP+ Multi-Source Agreement (MSA) mechanical specifications, ensuring compatibility with standard host cages from major switch and server manufacturers. Custom dimensional variants are available upon request for proprietary form factors.
Can these die-cast parts be supplied with surface plating or coating?
Yes. CZT can supply parts with nickel plating, tin plating, or chromate conversion coating applied post-casting. Surface treatment selection depends on the corrosion resistance, solderability, and EMI shielding requirements of the final transceiver assembly.
What is the typical production lead time for die-cast SFP+ structural parts?
For standard configurations with existing tooling, lead time is typically 2–4 weeks for production quantities. New tooling development for custom designs requires an additional 3–5 weeks for mold fabrication and first-article inspection before mass production begins.
SFP+Structural Part 1 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
