SFP+Structural Part 10
SFP+ structural part produced via precision die casting, designed to meet the mechanical and dimensional requirements of 10G transceiver module assemblies. High-quality alloy casting ensures consistent part geometry, surface integrity, and long-term reliability under repeated insertion cycles. Used in optical transceivers, media converters, and network interface cards across enterprise and carrier networks.
Key Features
- Meets SFP+ MSA mechanical and dimensional envelope requirements
- Precision die casting ensures consistent part geometry across high-volume runs
- Integrated structural features reduce need for secondary assembly operations
- Material selection optimized for thermal dissipation in active transceivers
- Compatible with automated pick-and-place assembly processes
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP+Structural Part 10 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
10G/25G SFP+ optical transceiver module production
Enterprise switch and router SFP+ port module frames
CWDM/DWDM transceiver housing structural components
Industrial automation fiber optic module assemblies
Wireless base station SFP+ interface module housings
Frequently Asked Questions
How does CZT ensure dimensional consistency across large production batches?
CZT uses calibrated die casting tooling with controlled injection parameters and in-process CMM (coordinate measuring machine) inspection. Statistical process control (SPC) is applied to critical dimensions, and first-article inspection reports are available to customers for qualification purposes.
What mechanical tests are performed on SFP+ structural parts?
Parts undergo dimensional inspection against customer drawings, surface finish evaluation, and mechanical strength testing including latch retention force and guide rail durability. Thermal cycling tests can be performed on request to validate performance in high-temperature transceiver operating environments.
Are custom alloy compositions available for specific thermal or EMI requirements?
Yes. CZT can work with customers to select or specify alloy compositions that balance thermal conductivity, EMI shielding effectiveness, and mechanical strength. This is particularly relevant for high-power SFP+ variants where heat dissipation through the housing is a design consideration.
SFP+Structural Part 10 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
