Industrial / Precision Die Casting
SFP Structural Part 10
Die-cast SFP structural part engineered for accurate dimensional conformance within standard SFP module assemblies, supporting reliable mating and retention in host equipment. Its precision construction contributes to the overall mechanical durability of the transceiver under industrial operating conditions. Commonly deployed in managed switches, media converters, and industrial Ethernet devices.
Key Features
- Precision die-cast construction ensures tight dimensional tolerances for SFP compliance
- Engineered for accurate mechanical conformance within standard SFP module assemblies
- High-strength alloy material provides durability under repeated mating cycles
- Surface finish optimized for EMI shielding and thermal dissipation
- Compatible with MSA-compliant SFP transceiver form factor specifications
Key Specifications
- Product type: precision die-cast structural component
- Connector / hardware family: SFP
- Process: precision die casting with secondary machining or finishing as required by drawing
- Application focus: connector housing, cage, shell, heatsink carrier, or industrial structural part
- +3 more specs below
Request drawing: This product has local image and specification coverage. Ask sales to confirm the latest drawing revision before sampling or tooling review.
SFP Structural Part 10 Specifications
Product typeprecision die-cast structural component
Connector / hardware familySFP
Processprecision die casting with secondary machining or finishing as required by drawing
Application focusconnector housing, cage, shell, heatsink carrier, or industrial structural part
Drawing statusRequest Drawing during RFQ; local PDF not available from the legacy archive
Asset statusOld-site product image available
RFQ checkconfirm alloy, dimensional tolerance, tooling status, surface finish, machining operations, inspection criteria, and drawing revision
Typical Applications
Fiber optic SFP transceiver module housing assemblies
Gigabit Ethernet and 10G optical network equipment
Industrial switch and router SFP cage integration
Telecom infrastructure optical transceiver manufacturing
Data center active optical cable module production
Frequently Asked Questions
What dimensional tolerances does SFP Structural Part 10 maintain?
This part is manufactured via precision die casting to meet MSA SFP mechanical specifications, maintaining tight tolerances that ensure plug-and-play compatibility across standard SFP cages and host equipment without requiring secondary machining.
What alloy is used in the die casting process?
CZT typically uses zinc or aluminum-based die casting alloys selected for their strength-to-weight ratio, corrosion resistance, and EMI shielding effectiveness — all critical properties for SFP transceiver structural components in demanding network environments.
Is this part compatible with both copper and optical SFP modules?
Yes. The structural geometry conforms to the SFP MSA standard, making it suitable for use in both optical fiber transceivers and copper SFP modules across 1G and compatible variants.
SFP Structural Part 10 Details
CategoryIndustrial
SubcategoryPrecision Die Casting
Naming TemplateProduct name from catalog
BrandCZT
OriginChina
Drawing StatusRequest drawing
